Rear Panel Features and Connections

ATTENTION:
ATTENTION:
The quantity of ports and corresponding front panel LEDs differs among IPL models, but the
functions of each type of port and their LEDs are identical for any model that includes that
type of port.
Power input
connector
(external
power supply)
(page 12)
Figure 6.
Installation and service must be performed by experienced personnel.
L'installation et l'entretien doivent être effectués par du personnel
expérimenté.
D D D D
POWER
MAC: 00-05-A6-XX-XX-XX
12V
S/N: ####### E######
0.2A MAX
POWER
12V COM 1
X.XA MAX
A A A A
1
Tx Rx G RTS CTS
COM 1
Tx Rx G RTS CTS
POWER
12V COM 4
X.XA MAX
Tx Rx G RTS CTS
IPL Pro Series Rear Panels
B B B B
IPL PRO S1
COM
Tx Rx G RTS CTS
LAN / PoE
IPL PRO S3
MAC: 00-05-A6-XX-XX-XX
00-05-A6-XX-XX-XX
MAC: 00-05-A6-XX-XX-XX
S/N: ####### E######
S/N: ####### E######
COM 2 COM 3
Tx Rx G RTS CTS Tx Rx G RTS CTS LAN / PoE
5-pole COM RS-232/RS-422*/
B B B B
RS-485* ports (page 13)
COM 2 COM 3
IPL PRO S6
MAC: 00-05-A6-XX-XX-XX
S/N: ####### E######
Tx Rx G RTS CTS Tx Rx G RTS CTS
COM 5 COM 6
LAN / PoE
Tx Rx G RTS CTS Tx Rx G RTS CTS
IPL Pro Series • Hardware Features and Installation
D D D D
LAN (Ethernet)
C C C C
connectors and
LEDs (page 14)
MAC address
D D D D
(page 14)
