External Connectors

This chapter describes the external connectors provided on the hp Integrity rx1620 Server.

Connector Pinouts

The following ports and connectors are found on the rear panel of the hp Integrity rx1620 Server.
• Dual USB 2.0
• Serial
• 68-pin LVD, SE U320 SCSI
• 10/100/1000 LAN
• AC power receptacle
Figure 3-1 Rear View of Server
10/100
LAN C
LVD/SE SCSI
Chapter 3
Optional
Management Board
Connectors
Video
Serial
10/100/1000 10/100/1000
LAN A 1Gb LAN B 1Gb
AC Power
Receptacle
PCI Slot 1
USB
Serial
PCI Slot 2
TOC
Half size
Locator Button
and LED
