Assembly and Operating Instructions
Art. No. CST-BC50
CSTBC50.01.01
Ergometer
BC50

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CST-BC50 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CARDIOSTRONG CST-BC50

Summary of Contents for CARDIOSTRONG CST-BC50

  • Page 1 Assembly and Operating Instructions Art. No. CST-BC50 CSTBC50.01.01 Ergometer BC50...
  • Page 2 BC50...
  • Page 3 Dear Customer, Thank you for deciding for a high-quality training equipment of the brand cardiostrong®, the brand that makes athlete‘s hearts beat faster. cardiostrong® offers a wide range of home fitness equipment like elliptical cross trainers, ergometers, treadmills and rowing machines. cardiostrong® equipment is the optimal equipment for all those who want to train at home independent of goals and fitness level.

  • Page 4: Table Of Contents

    CONTENTS GENERAL INFORMATION 1.1 Technical data 1.2 Personal safety 1.3 Electrical safety 1.4 Set-up place ASSEMBLY INSTRUCTIONS, MAINTENANCE AND CARE 2.1 General instructions 2.2 Faults and Troubleshooting 2.3 Maintenance and service calendar ASSEMBLY 3.1 Package contents 3.2 Assembly instructions OPERATING INSTRUCTIONS 4.1 Console display 4.2 Button functions 4.3 Turning on and setting up the equipment...
  • Page 5 WARRANTY INFORMATION DISPOSAL ORDERING ACCESSORIES ORDERING SPARE PARTS 9.1 Service hotline 9.2 Serial number and model name 9.3 Parts list 9.4 Exploded drawing...

  • Page 6: General Information

    GENERAL INFORMATION Technical data LED display Speed in km/h Training time in min Training distance in km Cadence (rotations per minute) Calorie consumption Heart rate (when using the hand pulse sensors or a chest strap) Power output in watts Resistance level User memory: Total number of workout programs: Manual programs:...

  • Page 7: Personal Safety

    Personal safety Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.

  • Page 8: Electrical Safety

    Electrical safety The equipment requires a 220 - 230V / 50 Hertz mains power supply. The equipment should be connected directly to a grounded plug socket only by means of the power cable supplied. The use of multi-socket adapters or similar is not recommended.

  • Page 9: Assembly Instructions, Maintenance And Care

    You should therefore immediately replace damaged or worn components. Please contact your contract partner in such a case. The equipment should no longer be used until it has been repaired. When needed, only use original cardiostrong® spare parts.

  • Page 10: Faults And Troubleshooting

    Check the tightness of all screw connections once a month. In order to be able to guarantee the constructively defined safety level of this equipment, we recommend having the equipment regularly maintained (at least once a year) by specialists (service technicians of your contract partner). The equipment may be cleaned of dust, dirt and sweat using a damp cloth.

  • Page 11: Maintenance And Service Calendar

    Maintenance and service calendar The following routine work must be done in the specified time intervals: Part Weekly Monthly 2x annually Annually Display console Tighten the pedals Plastic covers Seat rail Legends: C = cleaning; I = inspect...

  • Page 12: Assembly

    ASSEMBLY Package contents The package contains the parts represented in the illustration, including a power cable with mains plug. If one of the illustrated parts is missing, please contact your contract partner. BC50...

  • Page 14: Assembly Instructions

    Assembly instructions Before starting assembly, look carefully through the individual assembly steps shown and assemble the equipment in the order indicated. Step 1: 1) Install the front supporting foot (3) and the rear supporting foot (2) onto the main frame (1) with the help of the spring washer (7), the Allen screw (9) and the spacer (13). 2) Set the desired height by turning the wheel of the rear foot caps (29&30).
  • Page 15 Step 2: 1) Two people are required for this assembly step. 2) First, lift up the cover of the handlebar tube (64) as in fig. (a). Then, connect the upper console cable (52A) to the lower console cable (52B) as in fig. (b). 3) Connect the upper hand pulse cable (46) to the lower hand pulse cable (47).
  • Page 16 Step 3: 1) Attach the upper hand pulse cable (46) to the console (60). 2) Mount the console (60) on the handlebar tube (5) using the screws (111&110). 3) Connect the left and right pedals (16&106) to the cranks (105 & 15). BC50...
  • Page 17 Step 4: 1) Mount the handlebar (48) onto the main frame (1) using the Allen screw (8) and the curved washer (11). 2) Connect the plug of the lower hand pulse cable (47) to the upper hand pulse cable (46).
  • Page 18 Step 5: 1) Install the seat (42) on the seat post using the Allen screw (9A) and the spacer (13). 2) Mount the backrest (38) on the backrest supporting post using screw (120) and screw (121). 3) Connect the adapter (39) to the adapter input at the front of the equipment. 4) The backrest can be adjusted to the desired angle using the adjusting knob (35).

  • Page 19: Operating Instructions

    OPERATING INSTRUCTIONS Console display...
  • Page 20 Time display, ascending from 00:00-99:59 Time or descending from 99:00-00:00. 1-minute increments Speed Speed, given in km/h RPM (rotations per minute) RPM displayed in a bar chart Distance display, from 00:00-99.99 km; 0.1 km Distance increments Indicates the calories burnt, from 0-9999 calories Note regarding measurement of calorie Calories consumption: A general formula is used to...

  • Page 21: Button Functions

    Button functions Determining body fat percentage: Press and hold the BODY FAT button for two seconds, in order to change user data. A = AGE (in years) H = HEIGHT (in cm) W = WEIGHT (in kg) Testing the recovery heart rate Reset the settings or switch to the start-up screen Start and end workout Confirmation of settings...

  • Page 22: Turning On And Setting Up The Equipment

    Turning on the equipment Connect the power cable. An alarm will then sound. The LCD display fully illuminates for two seconds, including – for one second – “E” (EU) and “K” (KM). User profile Use the UP and DOWN buttons to select a user profile U1-U4 and press ENTER to confirm.

  • Page 23: M - Manual Program

    4.5.1 M - Manual program Select the manual program “M” from the program selection. Next, adjust to the desired resistance level (Level) using the arrow buttons UP and DOWN, and press ENTER to confirm. The resistance level can be adjusted at any time during the workout. If no change is made to the resistance for three seconds, the display changes to the “Watts”...

  • Page 24: H.r.c. - Heart-Rate Controlled Programs

    4.5.3 H.R.C. - Heart-rate controlled programs Use the arrow buttons UP and DOWN to select the heart symbol. Use the arrow buttons UP and DOWN to select the heart-rate programs 55%, 75%, 90% or TA (TA = Target = target heart rate). The heart-rate value is determined automatically based on the age previously entered and is then shown in the display.

  • Page 25: U - User-Defined Program

    4.5.5 U - User-defined program Use the arrow buttons UP and DOWN to select the user program “U”. Use the arrow buttons UP and DOWN to prepare a USER program. Using the arrow buttons, enter the resistance level for each segment and press ENTER to confirm.

  • Page 26: Recovery - Recovery Rate

    4.5.7 RECOVERY - Recovery rate The RECOVERY function can be used as long as a heart-rate reading is received throughout the workout. After finishing your workout, you can press the RECOVERY button to start a 60-second countdown, during which a heart-rate reading also needs to be received.

  • Page 27: Workout Instructions

    WORKOUT INSTRUCTIONS Heart-rate measuring Pulse measuring via hand sensors The hand sensors integrated in the handles beside the seat allow you to determine your heart rate. You can measure your heart rate by lightly grasping the sensors with both hands at the same time. Blood pressure changes occur due to the heartbeat. The sensors measure the changes to the electric skin resistance caused by it.
  • Page 28 while exercising. The transmitter turns on automatically once it is put on. In order to allow for a precise measuring, you should moisten the rubber electrodes. This is best done with a special chest strap contact gel, which is also used for ultrasound scans. Note: If you have not been active in doing sports for a longer period of time, you should first go to your physician in order to discuss your training with them.
  • Page 29 Example: For a 45-year-old man or woman, the maximum heart rate is 175 (220 - 45 = 175). • The fat burning target zone (55%) is at approximately 96 beats/min. = (220 - age) x 0.55. • The cardio target zone (75%) is at approximately 131 beats/min. = (220 - age) x 0.75.

  • Page 30: 10 Tips For Effective Ergometer Training

    10 tips for effective ergometer training 1. Set goals What would you like to achieve with your training? Weight regulation, improved stamina, prevent risk of disease, more mobility, cardiovascular training, etc. In order to achieve your long-term training goal, set individual partial goals, e. g., weekly or monthly goals.

  • Page 31: Designing A Workout

    9. Workout journal Keep a record of your training sessions. Note the date, resting pulse, active pulse, recovery pulse, resistance level, time, distance, calories burnt and fitness level. 10. Reward yourself Do something good for you and your body after training or after achieving a partial goal. Go to the sauna or a swimming pool.
  • Page 32 WEEK 5 + 6 Beginner Advanced Days Duration Intensity Duration Intensity 30 min. Moderate speed, keep 40 min. Vary speed, increase resistance low low resistance 30 min. Moderate speed, keep 40 min. Vary speed, increase resistance low resistance 30 min. Moderate speed, keep 40 min.

  • Page 33: Stretching Exercises For Leg And Chest Muscles

    Stretching exercises for leg & chest muscles Trapezius Splenius capitis Sternocleidomastoideus Trapezius Deltoid muscle Pectoralis major Deltoid muscle Elevator scapolae M. Teres major Triceps Rhomboid muscle Dentatus anterior Arm-radius muscle Biceps Major back muscle Obliquus externus Straight abdominal muscle Anconaeus Extensor Sartorius muscle digitorum...
  • Page 34 3. Exercise: Stretching the calf muscles (gastrocnemius) • Place feet parallel to each other pointing forward, the heels touch the floor • Support yourself on a chair coming from a lunge • Move your body weight to the front leg, press your heel from the rear leg towards the floor and hold the contact •...

  • Page 35: Workout Journal

    Workout journal Date Time (min.) Training weight Calories burnt Body weight Ø Pulse Distance Resistance level I feel ...

  • Page 36: Warranty Information

    WARRANTY INFORMATION cardiostrong‘s fitness equipment is subject to strict quality controls. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
  • Page 37 The terms of use are defined as follows: • Home use: solely for private use in private households up to 3 hours per day • Semi-professional use: up to 6 hours per day (e. g. rehabilitation centers, hotels, clubs, company gyms) •...

  • Page 38: Disposal

    Service outside of the warranty period We are also happy to issue an individual cost estimate if there is a problem with your fitness equipment after the warranty has expired, or in cases which do not fall under the terms of the warranty, e. g. normal wear and tear. Please contact our customer service team to find a quick and cost-effective solution to your problem.

  • Page 39: Ordering Accessories

    ORDERING ACCESSORIES Sport-Tiedje floor mat, size L Art. no. ST-FM-L Sport-Tiedje 122 kHz chest strap Art. no. ST1030 Chest-strap contact gel 250ml Art. no. BK-250 Fitness equipment care kit Art. no. HF-500...

  • Page 40: Ordering Spare Parts

    9:00 - 18:00 10:00 - 17:00 Serial number and model name Before assembling your equipment, find the serial number on the white sticker and enter it in the appropriate space. Serial number: Brand / category: Model name: cardiostrong recumbent ergometer BC50 BC50...

  • Page 41: Parts List

    Parts list Description Material Specification Qty. Main frame Rear stabilizer Q195 95.4*50.6*2.0Tx500L Front stabilizer Q295 95.4*50.6*2.0T*450 Screw ST4*1.41*15L Handlebar post tube Sliding beam Q195 50*100*1.8T*740L Spring washer D15.4 XD8.2x2T Allen bolt(anti-loosen) M8*1.25*50L,8.8grade Allen bolt M8x1.25x20L,8.8grade Bolt M8x1.25x15L,8.8grade Nylon Nut Q235A M8*1.25*8T Nylon nut Q235A...
  • Page 42 Description Material Specification Qty. 103*68*83 Rear foot cap(left) Idle wheel fixing plate Q235A 156*62.2*5T Spring D2.2*D14*55L Idle wheel NL+33% Fibre D23.8xD38x24 Q235A M10x1.5x10T Nylon nut Club knob Q235A+ABS D61*46 C ring 65Mn S-16(1T) Round side cap 6/8"x17 Backrest NL+fibre 500*470 Adaptor OUT:9V,500MA Rear chain cover (right)
  • Page 43 Description Material Specification Qty. D30*3T*520L,with hole,REACH Foam (HDR) mushroom cap D1 1/4"*29L Upper protective cover HIPS 137.1*121*73.4 Motor Q235A M10x1.5x10T nylon nut Allen bolt M8*25 15MM,8.8grade flat washer Q235A D21*D8.5*1.5T Plastic flat washer NL66 D10*D24*0.4T Side cap 30*70*17L Front decorative cover D91*220L D91*220L Rear decorative cover...
  • Page 44 Description Material Specification Qty. Q235A M5x0.8x12L cross Bolt Screw ST4.2x1.4x20L water bottle Q235A cross screw M5*0.8*15L Q235A+ABS D59*M10*40L Adjustable round wheel D6*26.5*7.7 bushing F101J D20*D14*11.5T Anti-loose nut Q23A 3/8"-26UNFx6.5T magnet NDFEB 39.5*10*25 Q235A cross screw M5x0.8x10L 170Lx9/16"-20BC Left crank 1015A Left pedal PP+Q235A JD-22A 9/16"...

  • Page 45: Exploded Drawing

    Exploded drawing...
  • Page 46 DISCLAIMER ©2010 cardiostrong® is a registered brand of the company Sport- Tiedje GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Sport-Tiedje is prohibited. Product and manual are subject to change. Technical data can be changed without advance notice.
