Assembly and Operating Instructions
max. 130 kg
~ 60 Min.
46 kg
L 108 | W 58 | H 143
Art. No. CST-BX60-2i
CSTBX602i.01.01
Art. No. CST-ICLCD (optional)
Upright Bike BX60 Smart

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CST-BX60-2i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CARDIOSTRONG CST-BX60-2i

Summary of Contents for CARDIOSTRONG CST-BX60-2i

  • Page 1 Assembly and Operating Instructions max. 130 kg ~ 60 Min. 46 kg L 108 | W 58 | H 143 Art. No. CST-BX60-2i CSTBX602i.01.01 Art. No. CST-ICLCD (optional) Upright Bike BX60 Smart...
  • Page 2 BX60 Smart...

  • Page 3: Table Of Contents

    Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Overview Initial Connection with iCardio Establishing the Bluetooth Connection OPTIONAL ICARDIO LCD CONSOLE Exchanging the Control Module Console Display Button Functions Turning on and Setting up the Equipment Programmes 4.5.1 Manual Programme Mode (MANUAL)
  • Page 4 RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT BX60 Smart...
  • Page 5 Train at home no matter what the weather or time of the day. cardiostrong fitness equipment offers training programmes and a variety of equipment for all training levels and all training goals. Further information can be found at www.sport-tiedje.com or www.cardiostrong.de.
  • Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
  • Page 7 A smartphone or tablet is not included in the scope of delivery. Alternatively, the built-in jog dial module can be exchanged for the cardiostrong iCardio LCD console for BX60 Smart. Further information on replacing the module can be found in these installation and operating instructions.

  • Page 8: General Information

    GENERAL INFORMATION Technical Data NOTICE The training data and programme variety mentioned below refer to the available data when connecting the equipment with the iCardio app via your mobile smart device. TFT display of speed in km/h training time in min training distance in km cadence (rotations per minute) calories burnt in kcal...

  • Page 9: Personal Safety

    Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.

  • Page 10: Electrical Safety

    Electrical Safety DANGER ⚠ In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠...

  • Page 11: Set-Up Place

    Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts.

  • Page 12: Assembly

    ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.

  • Page 14: Assembly

    Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. If you have difficulty recognising the graphics, we recommend that you open and/or download the PDF instructions stored in the webshop on your end device (e.g.
  • Page 15 Step 2: Assembly of the Front Stabilizer Attach the front stabilizer (B) to the main frame (A) with two screws (J1), two spring washers (J2) and two washers (J3). NOTICE If the machine is wobbly, you can adjust the end caps to stabilize the machine.
  • Page 16 Step 3: Assembly of the Central Tube NOTICE The central tube can be mounted at a standard or low setting according to height and personal preference. The main frame and the central tube are equipped with guiding labels for standard and low position.
  • Page 17 View 3-a: Standard position View A View B View A Standard position View B Standard positioning hole Standard (blue line) screw holes View 3-b: Low position View A View B View A position View B screw holes positioning hole (red line)
  • Page 18 Step 4: Assembly of the Water Bottle Holder Remove the preassembled screws (J10) from the central tube (D). Attach the water bottle holder (L) to the central tube (D) with the screws (J10). BX60 Smart...
  • Page 19 Step 5: Assembly of the Handle Bar Remove the preassembled screw (J10) from the central tube (D). Slide the handle bar (E) onto the central tube (D). Fasten the handle bar (E) to the central tube (D) with one knob (E2). Reattach the previously removed screw (J10) to the central tube (D).
  • Page 20 Step 6: Connecting the Cables Carefully pass the cable (D1) through the hole. Connect the plug (D3) to the hole of the handle bar (E). Step 7: Assembly of the Console Remove the preassembled screws (G1) on the back of the console (G). Connect the cables D1 and E1 with their respective components of the console (G).
  • Page 21 Step 8: Assembly of the Seat Position the seat (H) onto the seat basement (H4) and tighten it with the tool.
  • Page 22 Step 9: Assembly of the Pedals NOTICE The pedals and pedal straps are marked as left and right. Attach the right pedal (K2) to the right crank arm on the main frame (A) by turning the pedal (K2) clockwise. Attach the left pedal (K1) to the left crank arm on the main frame (A) by turning the pedal (K1) counterclockwise.
  • Page 23 Step 10: Connecting the Equipment to the Mains Supply ࣑ ATTENTION The equipment must not be connected to a multiple socket, otherwise it cannot be guaranteed that the equipment will be supplied with sufficient power. Technical errors can result. Plug the power plug into a wall outlet that complies with the instructions in the chapter on electrical safety.
  • Page 24 Adjustment of the Seat To adjust the seat (H) vertically, lift the wrench (F1) and adjust the seat (H) to the desired height. To adjust the seat (H) horizontally, loosen the knob (F2) and slide the seat (H) into the desired position.

  • Page 25: Operating Instructions

    OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Overview Tablet holder Android QR code QR code Jog dial Bluetooth number USB power charge...

  • Page 26: Initial Connection With Icardio

    Initial Connection with iCardio NOTE The following app is programmed and provided by external manufacturers. Changes and availability within the app might occur. Sport-Tiedje does not take any responsibility and can not be held liable for the availability, functionality or contents of this app. This device is intended to be used in combination with the iCardio app.

  • Page 27: Establishing The Bluetooth Connection

    Establishing the Bluetooth Connection Tap the small wheel symbol at the bottom left of the screen (fig. 2). This will take you to the settings. There you can, among other things, change the language of the app and open the operating instructions for the app. Tap the Bluetooth symbol (fig.

  • Page 28: Optional Icardio Lcd Console

    OPTIONAL ICARDIO LCD CONSOLE An optional iCardio LCD console is available for this specific equipment and can be purchased separately in the Sport-Tiedje webshop. The LCD console is exchangeable and can be swapped with the built-in jog dial module. The LCD console offers its own variety of programmes and training data. NOTICE The exchange of the module does not affect the compatibility with the iCardio app.

  • Page 30: Console Display

    Console Display Android QR code QR code iCardio LCD console Display of the training time Time Display range 0:00-99:59 minutes Display of the current speed Speed Display range 0.0-99.9 km/h or ml/h Display of the rotation per minute RPM (cadence; rotations per minute) Display range 0-999 RPM Display of the total distance Distance...

  • Page 31: Button Functions

    Display of the current wattage Watt Display range 0-999 Display of the current pulse Pulse (heart rate; heart beats per minute) Display range 0-230 BPM Display of the user profile U1 - U4 Manual workout mode MANUAL Watts workout mode WATTS Heart rate controlled workout mode H.R.C...

  • Page 32: Turning On And Setting Up The Equipment

    Turning on and Setting up the Equipment To turn on the equipment, connect the power cable to the equipment or press and hold the RESET button for two seconds. The console is powered on and displays all segments for 2 seconds. The wheel diameter and KM or ML is displayed for 1 second and resistance shows LOAD = 1.

  • Page 33: Manual Programme Mode (Manual)

    4.5.1 Manual Programme Mode (MANUAL) There are two ways to enter the manual mode: Without settings To select quick-start and start training immediately, press START/STOP. You automatically enter the manual programme. The resistance level can be adjusted during the workout. To pause the workout, press START/STOP.

  • Page 34: Pre-Set Programme Mode (Program)

    4.5.2 Pre-set Programme Mode (PROGRAM) To select PROGRAM mode, use the UP/DOWN buttons and confirm with MODE. To select one of the twelve pre-set programmes (P01 - P12), use the UP/DOWN buttons and confirm your selection with MODE. The selected programme flashes in the display. The default load value (1) flashes until confirmed (fig. 10 &...

  • Page 35: User-Defined Programme Mode (User)

    4.5.3 User-Defined Programme Mode (USER) The user-defined programme allows you to create your own profile programme by individually setting the resistance level for up to 10 segments. Each user profile can set one user-defined programme. To select the USER mode, use the UP/DOWN buttons and confirm with MODE. To set the resistance level for a segment, use the UP/DOWN buttons and confirm with MODE (fig.

  • Page 36: Heart Rate Controlled Programme Mode (H.r.c)

    4.5.4 Heart Rate Controlled Programme Mode (H.R.C) ⚠ WARNING Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. Various factors can affect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid. The console has an integrated heart-rate receiver.

  • Page 37: Watt Controlled Programme Mode (Watt)

    4.5.5 Watt Controlled Programme Mode (WATT) To select the WATT mode, use the UP/DOWN buttons and confirm with MODE. The preset wattage 120 flashes in the display. To set the desired wattage between 10 and 350 watts, use the UP/DOWN buttons and confirm with MODE.

  • Page 38: Storage And Transport

    STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑...

  • Page 39: Troubleshooting, Care And Maintenance

    TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner.

  • Page 40: Maintenance And Inspection Calendar

    Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Plastic covers Screws and cable connections Check pedals for tightness Legend: C = clean;...

  • Page 41: Recommended Accessories

    RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape.

  • Page 42: Ordering Spare Parts

    The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: cardiostrong / upright bike Model Name: BX60 Smart iCardio LCD console for BX60 Smart (optional) Article Number:...

  • Page 43: Parts List

    Parts List Name Qty. Name Qty. MAIN FRAME BEARING 6004ZZ SENSOR WIRE 850mm BUSH Φ25xΦ20x26mm CHAIN COVER‐L SPACER Φ25xΦ20x5mm CHAIN COVER‐R SMALL BELT WHEEL Φ41 FRONT CHAIN COVER - L PARALLEL KEY FRONT CHAIN COVER - R WASHER M8 PLASTIC COVER - L BUSH Φ22.5xΦ26xL18.5 PLASTIC COVER - R SCREW M8x20...
  • Page 44 FIX PLATE SPONGE HDR SCREW M5x25mm SPONGE HDR SCREW M6X12mm END CAP Φ37.5 BOLT END CAP NUT M3 BUSH M9x26mm SCREW M4X16mm UPPER HANDLE PULSE HOUSING NUT M4 LOWER HANDLE PULSE NUT M3 HOUSING SOCKET Φ10xΦ15xL9 SCREW M3x10 SCREW M6 WASHER Φ6xΦ12x2T SEAT TUBE WASHER Φ3xΦ6x0.5T...
  • Page 45 C CLIP M11 SPRING END CAP LATCH CONSOLE SADDLE SCREW SLEEVE M10x7mm WASHER M10 SLIDE RAILS END CAP STICKER LEVER COVER - L LEVER COVER - R SCREW M5x10mm SCREW M10x90mm SPRING WASHER M10 WASHER M10 SCREW M5x10mm SCREW M10x110mm WASHER M12 SCREW M8x16mm SPRING WASHER M8...

  • Page 46: Exploded Drawing

    Exploded Drawing BX60 Smart...

  • Page 47: Warranty

    WARRANTY Training equipment from cardiostrong® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
  • Page 48 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.

  • Page 49: Contact
