Assembly and Operating Instructions
max. 150 kg
~ 30-60 Min.
47 kg
L 96 | W 56 | H 143
CSTBX70i.02.07
Art. No. CST-BX70i-2
Ergometer BX70i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ergometer BX70i and is the answer not in the manual?

Questions and answers

Related Manuals for CARDIOSTRONG Ergometer BX70i

Summary of Contents for CARDIOSTRONG Ergometer BX70i

  • Page 1 Assembly and Operating Instructions max. 150 kg ~ 30-60 Min. 47 kg L 96 | W 56 | H 143 CSTBX70i.02.07 Art. No. CST-BX70i-2 Ergometer BX70i...
  • Page 2 BX70i...

  • Page 3: Table Of Contents

    Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console display Button Function Turning On and Setting the Equipment Training programme 3.4.1 MANUAL MODE 3.4.2 PROGRAM MODE 3.4.3 H.R.C. MODE 3.4.4 WATT MODE 3.4.5 USER PROGRAM MODE 3.4.6 RECOVERY...
  • Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT BX70i...
  • Page 5 Train at home no matter what the weather or time of the day. cardiostrong fi tness equipment off ers training programmes and a variety of equipment for all training levels and all training goals.
  • Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and fi rst use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
  • Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ATTENTION This notice indicates potentially hazardous situations which, if not avoided, may result in property damage.

  • Page 8: General Information

    GENERAL INFORMATION Technical Data LED display of speed in km/h training time in min training distance in km cadence (rotations per minute) calories burnt heart rate (when using the hand sensors or a chest strap) watt resistance level Resistance system: electromagnetic induction brake Resistance level: Watt:...

  • Page 9: Personal Safety

    Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly aff ected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.

  • Page 10: Electrical Safety

    ⚠ CAUTION Be aware that if adjustment devices are left protruding, they may impede the user’s movement. ATTENTION Do not insert any objects of any kind into the openings of the device. To protect the equipment from use by unauthorised third parties, always remove the power cable when not in use and store it in a safe place that is inaccessible to unauthorised persons (e.g.

  • Page 11: Set-Up Place

    Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts.

  • Page 12: Assembly

    ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suff ocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.

  • Page 13: Scope Of Delivery

    Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. ⚠...
  • Page 14 10 & & BX70i...

  • Page 15: Assembly

    Acrobat Reader programme must be installed on your end device in order to open the fi le. The assembly can also be found as a video under the following link: https://www.sport-tiedje.co.uk/cardiostrong-exercise-bike-bx70i-cst- bx70i-2#product-assembly. To go directly to the assembly video, you can alternatively scan the QR-code.
  • Page 16 Step 2: Assembly of the saddle and seat tube Mount the seat (10) on the adjusting tube of the seat (11). Mount the adjusting tube on the seat post (66) with the help of the round cross screw (16) and quick-released knob (15).
  • Page 17 Step 3: Assembly of the handlebar tube This assembly step should be executed by at least two persons. First take the upper protective cover (28) off (see fi gure a). Then connect the computer cables (72 & 73) (see fi gure b). Insert the handlebar tube (29) on the main frame and mount this with the spacer sleeve (7), spring washer (8) and socket screw (30).
  • Page 18 Step 4: Assembly of the handlebars Mount the handlebars (32) on the handlebar tube (29) by means of the protective cover (65), the spacer sleeve (7), the spring washer (8), the socket screw (9) and the screw (20). Make sure that all cables are correctly connected, see fi gure a, b, c, d. M8*20 D15.4 M5*15...
  • Page 19 Step 5: Assembly of the console & pedals Connect the upper computer cable (72) and the hand pulse cable (68) with the computer (17) and mount the computer (17) on the handlebar tube (29) by means of the screw (64). ⚠...
  • Page 20 Step 6: Alignment of the Feet If the fl oor is uneven, you can stabilize the equipment by turning the two setting screws under the main frame. Lift the equipment on the desired side and rotate the setting screws under the main frame. Rotate the screws clockwise in order to remove them and to raise the equipment.

  • Page 21: Operating Instructions

    OPERATING INSTRUCTIONS  NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Always start your training with low intensity and increase evenly and gently. End your training with a cool-down phase.
  • Page 22 When no target is set, the time counts up from 00:00 to a maximum of 99:59. Time When you work out with a pre-set time, the time counts from the pre-set time down to 00:00. Every pre-set increment is one minute from 00:00 to 99:00. Speed Displays theh current training speed from 00.0 to 99.9 km/h.

  • Page 23: Button Function

    Button Function + (encoder) Increase the resistance level. Increase values. Choose a programme. - (encoder) Reduce the resistance level. Reduce the values. Choose a programme. Mode / Enter Confi rm setting of selection. Hold pressed for two seconds to reboot the computer and to start with the user settings.

  • Page 24: Training Programme

    Fig. 1 Fig. 2 Fig. 3 Training programme Select the training with the encoder: M (Manual) + P (Programme 1 to 12) + H.R.C. (heart rate controlled) + W (Watts) + U (User). Confi rm the programme with MODE/ENTER. 3.4.1 MANUAL MODE Press START in the main menu to start directly the training in the manual mode.

  • Page 25: Program Mode

    Fig. 4 Fig. 5 Fig. 6 Fig. 7 Fig. 8 Fig. 9 3.4.2 PROGRAM MODE Select a training programme with the encoder. Select P01, P02, P03, etc. and confi rm your settings with MODE/ENTER. Set the intensity level with the encoder (fi g. 10). The default value is 1. Enter the time with the encoder.

  • Page 26: H.r.c. Mode

    Fig. 10 3.4.3 H.R.C. MODE ⚠ WARNING Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. Various factors can aff ect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid. Select a training programme with the encoder.

  • Page 27: Watt Mode

    3.4.4 WATT MODE Select a training programme with the encoder. Select W and confi rm with MODE/ENTER. Set the WATT target (default value: 120, fi g. 15) with the encoder. Enter the time with the encoder. Press START/STOP to start the training. During the training, the system adjusts automatically the intensity level according to the pedalling speed to keep the wattage (resistance) constant.

  • Page 28: Recovery

    3.4.6 RECOVERY After the training, you hold the handles with both hands or wear a chest strap and press the RECOVERY button. The display of all functions is stopped except for TIME. The time starts to count down from 00:60 to 00:00 (fi g. 17). The screen displays your heart rate recovery state with F1, F2, to F6 (fi g.
  • Page 29 Fig. 19 Fig. 20 Fig. 21 Fig. 22 Fig. 23 Fig. 24 Fig. 25  NOTICE After 4 minutes without pedaling or pulse input, console will enter into power saving mode. Press any key may wake the console up. When computer act abnormal, please plug out the adaptor and plug in again.

  • Page 30: Connection With Kinomap

    For the BX70i, select Exercise bike/recumbent bike. On the next page you will see the diff erent brands. Select “cardiostrong” and then the BX70i. Now all Bluetooth sources in the surrounding area are displayed. Select a Bluetooth source that begins with i-Console ..
  • Page 31 Under the QR code provided, you can watch the video of the connection with Kinomap. (https://www.youtube.com/watch?v=KGnhAQJDlFA) The BX30 Plus has the same console as the BX70i, here we demonstrate the connection in a video.  NOTICE The pre-installed apps are produced and provided by external manufacturers. Changes and availability within these apps might occur.

  • Page 32: Storage And Transport

    STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location.

  • Page 33: Troubleshooting, Care And Maintenance

    TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. ⚠ CAUTION Damaged or worn components may aff ect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner.

  • Page 34: Error Codes And Troubleshooting

    Error Codes and Troubleshooting The electronics of the equipment continuously carries out tests. In case of deviations, an error code appears on the display and normal operation is stopped for your safety. The display shows === + The handles are not correctly grasped with both hands. E1 + There is no heart rate signal.

  • Page 35: Disposal

    DISPOSAL At the end of its operational life, this equipment cannot be disposed of in normal household waste. Instead, it must be disposed of via an electricals recycling centre. Further information can be obtained from your local authority‘s recycling service. The materials can be recycled as per their symbols.

  • Page 36: Recommended Accessories

    RECOMMENDED ACCESSORIES To make your training experience even more effi cient and pleasant, we recommend that you add suiting accessories to your fi tness equipment. For exercise bikes this could for example be a fl oor mat, which makes your fi tness equipment stand more securely and also protects the fl oor from sweat or silicone spray to keep moving parts in good shape.
  • Page 37 The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate fi eld. Serial number: Brand / Category: cardiostrong / exercise bike Model Name: BX70i Article Number: CST-BX70i-2...
  • Page 38 Parts List Qty. Name Supplier Parts No. Specifi cation Main frame 815S0-3-1000-J2 Rear stabilizer 709S0-6-2107-J2 95.4*50.6*2.0Tx500L Adjustable wheel 709S0-6-2174-B0 D59*M10*40L Front stabilizer 832S0-3-2100-J0 Tri-angle cap(left) 55357-B-5095-B8 95.7*57.2*51.3 Tri-angle cap(right) 55357-A-5095-B8 95.7*57.2*51.3 Flat washer D16*D8.5*1.2T 55108-1-1612-FA D16*D8.5*1.2T Spring washer D15.4 XD8.2x2T 55108-2-1520-FA D15.4 XD8.2x2T Allen bolt M8x1.25x20L...
  • Page 39 Left crank 58007-6-1082-D0 170Lx9/16"-20BC Left chain cover 81502-6-4501-V20 534.7*502*78.1 Right chain cover 81502-6-4502-V20 534.7*502*82.7 Allen nut M6*1.0*6T 55206-2-2006-NA M6*1*6T Adjustable bolt 84302-6-3302-N0 M6*1.0*46 Round cycle for chain cover 81502-6-4503-B0 117*58*9.3 EMS system 801S0-3-3102-05 D265*86 Allen bolt M8x1.25x50L 50308-5-0050-C0 M8x1.25x50L Flat washer D13*D6.5*1.0T 55106-1-1310-NA D13*D6.5*1.0T Spring washer D10.5*D6.1*1.3T...
  • Page 40 Connecting cable 820S0-6-3177-00 350L Upper computer cable 801S0-6-2572-01 1000L Lower computer cable 815S0-6-2573-00 1800L Sensor cable 818S0-6-2576-00 450L Knob 52916-2-0022-G1 D50xM16x22xD8 Inner tube 195E5-6-1071-B0 40x80x129 Flat washer D24*D16*1.5T 55116-1-2415-NA D24*D16*1.5T Round wheel 84302-6-2175-00 D70.5*23 Bolt M5x0.8x12L 52605-2-0012-N0 M5x0.8x12L Allen bolt M8*1.25*40L 50308-5-0040-F3 M8*1.25*40L Adaptor...
  • Page 41 Exploded Drawing 60 77 49 59 54 51 53 52 55 56 34 33 18 27 26 72 73...
  • Page 42 WARRANTY Products from cardiostrong® are subject to strict quality control. However, if a fi tness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
  • Page 43 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
  • Page 44 CONTACT TECHNIK TEKNIK OG SERVICE CUSTOMER SUPPORT �� �� �� +49 4621 4210-900 80 90 16 50 00800 2020 2772 +494621 4210 944 +49 4621 4210-945 �� +49 4621 4210-698 �� �� info@fi tshop.dk info@fi tshop.co.uk �� technik@fi tshop.de �� ��...
