Error Message; Appendix A: 9D24 Mkll Functionality With A 9D23 Sim - ASCOM 9d24 MkllMessenger User Manual

User Manual
9d24 Mkll Cordless Telephone

10.1 Error message

Error message
Check SIM card
SIM failure
Consult manual
EEPROM failure
Service needed
Note: Some error codes shows only in english.

Appendix A: 9d24 Mkll Functionality with a 9d23 SIM

The 9d24 MkII Cordless Telephone can be used with a 9d23 SIM card but the functionality
will be limited as described below.
9d24 Mkll Functions that are not working
• Man-down alarm does not work.
• Central phonebook from Contacts menu is not available.
• Modes are not available.
• Switch off from modes menu is not possible.
• Services are not available.
• Internal call, External call and Callback will have the same Ring signal setting.
• Soft keys cannot be used.
• Some Hot key short-cuts cannot be used, see
9d24 Mkll Functions that are working
• Phone calls to and from the handset
• Messages
• SMS from the handset
• Interactive Messaging
• Push-button alarms
• No-movement alarm
• Pull-cord alarm works but has to be activated every time the handset is restarted.
Hot keys
The 9d23 and 9d24 Mkll do not have the same set of Hot key functions. When the Hot
keys on a 9d23 SIM are programmed with functions, the following applies:
9d23 Function
Manual absent on
Manual absent off
Switch off
Change system
No-movement alarm on
2006-03-20/ Ver. PA8
PRELIMINARY
Solution
Check that a 9d24 or 9d23 SIM card is used and that
the SIM card is properly positioned.
The SIM card has corrupt data and needs to be
replaced. Contact the system administrator.
Malfunction detected, handset needs repair.
9d24 Mkll Short-cut
Absent on/off
Pull-cord alarm on/off
Switch off
Change system
No-movement alarm on/off
Hot keys for more information.
TD 92333GB
45
