User Manual
9d24 Mkll Cordless Telephone
Note: It is not possible to charge spare batteries in the Desktop Charger.
9.2

Remove the Battery

The battery is fastened by a screw and two hooks. To remove the battery, use a small coin
and turn the screw to horizontal position. Remove the battery by pulling the screw. When
fastening the battery again the screw has to be in horizontal position.
Note: Avoid using a screwdriver as it may damage the screw.
9.3

Change the SIM Card

Remove the battery as described above. Slide the SIM card out of position. Insert the new
SIM card and slide it into position.
9.4

Change the Clip

A hinge-type belt clip is mounted on the 9d24 Mkll Cordless Telephone at delivery. The clip
can be replaced with a covering plate that is in the delivery or a swivel-type belt clip that
can be ordered separately.
Tools required:
• Pozidriv Point size 1
9.5

Attach Pull-cord Protection Plug

Disable the pull-cord alarm, see
Remove the pull-cord and replace it with the Protection plug.
10

Trouble Shooting

Problem
The handset do
not start
2006-03-20/ Ver. PA8
PRELIMINARY
6.5.7 Deactivate/Activate Pull-cord alarm
Solution
Check that the correct battery type is used. "Only to
be used in RAID2-XXXXX" should be printed on the
label on the battery. If the battery is correct make sure
it is fully charged.
TD 92333GB
on page 32.
44
