9

Maintenance

9.1

Charge the Battery

The battery requires charging when the battery icon in the handsets display is empty.
Place the handset in the charger. A beep indicates connection with the charger. The
charging status is shown by the battery icon in the handset display. After approximately
two (Desktop Charger) / four (Charging Rack) hours the handset is fully charged, indicated
by a filled battery icon.
If the handset is switched off automatically due to low battery and placed in a charger the
handset will be switched off but charged. The charging starts within 5 seconds. To start
the handset press and hold the Call key; the question "Switch on?" will be displayed.
Press "Yes" within 10 seconds.
If a call is connected when the handset is placed in the charger the handset will be
charged and fully operational at the same time.
Note: Charging below 0°C will harm the battery and shorten the lifetime.
Note: The handset can be charged in the wall-mounted charger without removing the
pull-cord catch.
9.1.1

Charging Spare Batteries

Spare batteries can be charged in the wall-mounted Charging Rack equipped with the
battery pack adapter.
Figure 11. Inserting a battery in the Charging Rack equipped with an adapter.
Place the battery in the charging slot. The LED on the adapter starts flashing green, one
flash per two seconds, see
LED will show a steady green light.
If the LED does not start to flash when the battery is placed in the charging slot, the
battery is not in contact with the adapter. If the LED flashes rapidly, two flashes per
second, is indication an error. Remove the battery and put it into the charging slot again.
2006-03-20/ Ver. PA8
PRELIMINARY
LED
figure 11 on page 43. When the battery is fully charged, the
