User Manual
9d24 Mkll Cordless Telephone
3.3

SMS (Short Message Service)

Note: 9d24 Messenger and 9d24 Protector only.
SMS messages can be sent from one handset to another. A Soft/Hot key and a Service can
be programmed with a SMS function.
An incoming SMS is immediately displayed and the number of the sending handset is
shown on a separate row.
Sending SMS is a system dependent function.
3.3.1

Send an SMS

There are three ways to send an SMS:
• Select the Messages tab and press the Navigation key (down) to enter "Send SMS".
• A programmed Soft/Hot key, see
• Use Service, see
Enter the destination address or fetch it from the Local phonebook by pressing the Soft
key with the "Contacts" icon; press "Ok". It is possible to program the Soft/Hot key and
the Service with a predefined destination address. If the address is not entered, an error
message will be displayed. Enter text and press "Send". "Sending" will be displayed as a
confirmation of the transfer.
3.3.2

Send an SMS to a predefined Destination Address

Press the Soft key, press and hold the Hot key, or select the Service. Enter text and press
"Send". "Sending" will be displayed as a confirmation of the transfer.
3.3.3

Display and Scroll between SMS Messages

SMS messages are saved along with other messages in the message list. Press the
Navigation key (up) to enter the message list. Use the Navigation key (up/down) to step in
the list. Only one row per message is displayed. Press Navigation key (right) to see the
whole message. The time and date the SMS was received and the number of the sending
handset is also shown.
3.4

Interactive Messaging

Note: 9d24 Mkll Messenger and 9d24 Mkll Protector only.
Interactive Messaging (IM) is a function that extends basic messaging. It makes it possible
for a user of a handset to access information from a client application in the system.
An example can be a customized application that can be accessed from the handset. A list
of actions can be included in the message sent from the application to the handset.
Mobile data from the handset can initiate the application to send the interactive message,
see 3.5 Mobile Data
action can be sending a message back to the application and/or dialling a specific number
etc.
An IM is indicated and viewed the same way as an ordinary message, see
Text Message
message. It is saved along with other messages in the message list.
2006-03-20/ Ver. PA8
PRELIMINARY
6.5.8 Edit a Soft key
6.4 Services on page 29.
on page 15. The user can then select one action from the list. The
on page 13, but the "Interactive message" icon is added in front of the
TD 92333GB
on page 32.
3.2.2 Receive a
14
