7.

Programming

The Pancode VoIP/Pantel VoIP units are programmed through web-based GUI interface. This process can be
implemented after the unit has been installed on the wall, since it requires the connection of an Ethernet cable
to the local network.
The programming application is launched from the web browser (preferably MS Internet Explorer version 5.5 or
higher). It is possible to run the application by typing the following address in the address bar:
http://XXX.XXX.XXX.XXX/pancode
7.1

Searching for a Device in LAN

When the IP address is unknown, it is possible to find the unit in the LAN using the QUERY utility from the
installation CD.
To find the unit in the network:
a. Insert the installation CD and copy the query.exe file from Software directory to the local hard drive.
b. Start MS Windows DOS prompt application.
c. Access the directory, in which the query.exe application exists.
d. Enter the following command: query XX:XX:XX:XX:XX + <Enter>, where XX:XX:XX:XX:XX is the MAC
address. A search for the device takes place, at the end of which the unit IP address appears (Figure 11).
Pancode VoIP/Pantel VoIP Access Control Door Phones
(Figure 10).
Figure 10. ITS Pancode IP Web Page
Unit location through a query is possible only when the unit MAC
address is known. It appears on the label attached to the rear panel
of the device.
Figure 11. Searching for Device Using Query
Installation and Programming Manual
13
