Parameter
User Domain
Registar Address (Proxy IP
field)
Registar port (Proxy Port field)
Auto Registration
Registration expire
(Registration Interval)
Codec Type
Unit Volume level
Far End (Speaker) Volume
Level
VAD (Voice Activity
Detection) Threshold
Auto Start
DSP Firmware version (Voice
Operational Mode)
Enable DHCP
Product Type
Dial Mode
Pancode VoIP/Pantel VoIP Access Control Door Phones
Description
In most cases it is the same as the Registar Address (Proxy server IP
address). In special cases it is required to enter Company Domain IP
address.
An identifier for the SIP Proxy server on a TCP/IP network. Legal entry: 0-9
digits only. Example: 192.14.21.210.
Designed to contain the number of the TCP/IP port used by the unit for
communication with SIP Proxy server (IP-PBX). Default port: 5060. Legal
entry: Up to 8 digits (0..9).
Displays the time interval for the unit to register on the Proxy server and to
indicate Live status. Legal entry: 0-9999. The setting in this field takes
effect only when Enable Auto Registration checkbox is selected.
A Low/MU Low options – enable to select between VoIP codecs
supported by the PBX.
Microphone Volume – enables to set the microphone volume level as a
two-digit parameter. Legal entry: 00 – 63 (00 sets Mute mode).
Speaker Volume – enables to set the speaker volume level as a two-digit
parameter. Legal entry: 00 – 63 (00 sets Silent mode).
When checkbox is selected, activates a field under it. This field contains a
virtual value (0-256) that represents a threshold for human voice
detection. When voice is detected, the unit will establish a connection
with the extension according to the programming in Day and Night
numbers (recommended value 20-25).
This parameter is required for manufacturing purposes only.
Switching between Full and Half duplex voice transmission modes. Legal
entry: 1 – half-duplex mode; 2 – full duplex mode.
Enables DHCP service support. IP Door panel will get IP settings
automatically in case that DHCP server is present in the LAN.
List of available IP Door Panel configuration and functionality. These
settings define the device functionality as a panel or Pancode.
Standard dialing – sets the unit to standard dialing operation mode. In
this mode, it is possible to make a direct call to an extension or enter a
door-opening access code.
Speed-dialing – sets the Pancode VoIP to speed-dialing operation mode.
In this mode, it is possible to make a call using a two-digit speed dial code
(11 to 35) to internal or external subscribers.
