4.
Pancode VoIP/Pantel VoIP Schematic Setup
The Pancode VoIP/Pantel VoIP unit is connected to the VoIP PBX as a SIP extension or via any IP router (Network
HUB, Switch etc). The unit powers the door lock, provided it is powered by an external supply and not PoE.
Figure 4 details the unit schematic setup.
Extension
TV Monitor
Pancode VoIP/Pantel VoIP Access Control Door Phones
PBX
Pancode VoIP/
Pantel VoIP
Figure 4. Schematic Setup
Installation and Programming Manual
VoIP Network/
LAN
Door Lock
7
