Metra Electronics 99-7427 Installation Instructions

Nissan Maxima 2009-2014
KIT FEATURES
• DIN Radio Provision With Pocket
• ISO DIN Radio Provision With Pocket
• PAINTED TO MATCH FACTORY DASH:
99-7427B=BLACK, 99-7427G=GRAY
• Textured To Match Factory Dash
KIT COMPONENTS
• A) Radio Housing • B) Trim Plate • C) ISO Brackets • D) Module Brackets • E) (2) Phillips Head Screws
A B
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • 70-7552
Antenna Adapter: • 40-NI12
TOOLS REQUIRED
• Torx Screwdriver • Panel Removal Tool • Phillips Screwdriver
METRA. The World's best kits.
Installation instructions for part 99-7427
(non nav models) (w/o tech package)
99-7427
C D
metraonline.com
™
Table of Contents
Dash Disassembly ................................................. 2
Kit Preparation ....................................................... 2
Kit Assembly
– DIN Radio Provision With Pocket ........................... 3
–
ISO DIN Radio Provision With Pocket .................... 3
E
CAUTION!
Metra recommends disconnecting the negative bat -
tery terminal before beginning any installation, unless the vehicle
manufacturer recommends against so. Please check with your local
Dealership for more information. All accessories, switches, climate
controls panels, and especially air bag indicator lights must be con -
nected before reconnecting the battery or cycling the ignition. Also,
do not remove the factory radio with the key in the on position, or the
vehicle running. It would be best to remove the key from the ignition
and then wait a few seconds before removing the factory radio.
© COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION
