- Page 1 KEEX-8100 Series 3.5" ECX Single Board Computer ® with Intel Haswell M Processors User’s Guide KEEX-8100 Series Use r’s Manual...
- Page 2 © 2015 Quanmax Inc. All rights reserved. The information in this user’s guide is provided for reference only. Quanmax does not assume any liability arising out of the application or use of the information or products described herein. This user’s guide may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of Quanmax, nor the rights of others.
-
Page 3: Table Of Contents
Memory Module Installation ................35 Chapter 4 AMI BIOS Setup ....................37 Overview ........................37 Main Menu ......................38 Ad vanced Menu ....................39 Boot Menu......................51 Security Menu .......................52 Save & Exit Menu ....................53 KEEX-8100 Series Use r’s Manual... - Page 4 Content Chapter 5 Driver Installation .....................55 Appendix A DIO (Digital I/O) Sample Code ..............56 Appendix B WatchDog Timer Sample Code ..............58 KEEX-8100 Series Use r’s Manual...
-
Page 5: Figures
Figure 4 Jumper and Connector Locations ............21 Figure 5 Rear Panel IO..................24 Figure 6 Align the SO-DIMM Memory Module with the onb oard socket ..35 Figure 7 Press down on the SO-DIMM Memory Module to lock it in place .36 KEEX-8100 Series Use r’s Manual... -
Page 6: Tables
Tables Tables Table 1 KEEX-8100 Series Specification............17 Table 2 Jumper List ....................22 Table 3 JP1 MPCIE Activity LED Indication ...........22 Table 4 JP2 SRTC Reset Selection..............22 Table 5 JP3 RTC Reset Selection ..............22 Table 6 JP4 Backlight Power Enable Selection for LVDS1 ......23 Table 7 JP5 Panel &... - Page 7 Table 53 Ad vanced Menu –Super IO Configuration – Serial Port 2 Configuration ....................49 Table 54 Ad vanced Menu –H/W Monitor ............50 Table 55 Boot Menu ....................51 Table 56 Security Menu ..................52 Table 57 Save & Exit Menu..................53 KEEX-8100 Series Use r’s Manual...
-
Page 8: Safety Instructions
Use extreme caution when installing or removing components. Refer to the installation instructions in this user’s guide for precautions and procedures. If you have any questions, please contact Quanmax Post-Sales Technical Support. WARNING High voltages are present inside the chassis when the unit’s power cord is plugged into an electrical outlet. -
Page 9: Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. Quanmax strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment. - Page 10 Handle components and boards with care. Don’t touch the components or contacts on a board. Hold a board by its edges or by its metal mounting bracket. Do not handle or store system boards near strong electrostatic, electromagnetic, magnetic, or radioactive fields. KEEX-8100 Series Use r’s Manual...
-
Page 11: Preface
Remove all items from the box. If any items listed on the purchase order are missing, notify Quanmax customer service immediately. Inspect the product for damage. If there is damage, notify Quanmax customer service immediately. Refer to “Warranty Policy” for the return procedure. -
Page 12: Warranty Policy
Quanmax or its authorized agent; or if the failure is caused by accident, acts of God, or other causes beyond the control of Quanmax or the manufacturer. Neglect, misuse, and abuse shall include any installation, operation, or maintenance of the product other than in accordance with the user’s guide. -
Page 13: Maintaining Your Computer
Quanmax. Limitation of Liability In no event shall Quanmax be liable for any defect in hardware, software, loss, or inadequacy of data of any kind, or for any direct, indirect, incidental, or consequential damages in connection with or arising out of the performance or use of any product furnished hereunder. - Page 14 Line conditioners keep a system’s AC power source voltage at a fairly constant level and, therefore, can handle brownouts. Because of this added protection, line conditioners cost more than surge protectors. However, line conditioners cannot protect against a complete loss of power. KEEX-8100 Series Use r’s Manual...
- Page 15 Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. KEEX-8100 Series Use r’s Manual...
-
Page 16: Chapter 1 Introduction
Introduction Overview The KEEX-8100 series is an Intel® embedded compact extended form factor single board computer (SBC) that equips Intel® Haswell with HM87/QM87 Express Chipset. Featured are DDR3/L SO-DIMM, 2x GbE, 1 x LVDS, 1 x D VI-I, 1 x HD MI, 4x USB3.0, 2x USB2.0, DIO, and 2x COM. -
Page 17: Product Specifications
ATX/AT Mode & ACPI 4.0a support 0°C ~ 60°C / 32°F ~ 140°F (Standard) Operation Temp. -20°C ~ 70°C / -4°F ~ 158°F ( Extended) Certifications CE, FCC Class A Table 1 KEEX-8100 Series Specification KEEX-8100 Series Use r’s Manual... -
Page 18: System Block Diagram
Chapter 1 System Block Diagram Figure 1 Block Diagram KEEX-8100 Series Use r’s Manual... -
Page 19: Mechanical Dimensions
Chapter 1 Mechanical Dimensions Figure 2 Mechanical Dimensions KEEX-8100 Series Use r’s Manual... -
Page 20: Chapter 2 Hardware Settings
No.1. To move a jumper from one position to another, use needle-nose pliers or tweezers to pull the pin cap off the pins and move it to the desired position. KEEX-8100 Series Use r’s Manual... -
Page 21: Jumper Settings And Pin Definitions
Chapter 3 Jumper Settings and Pin Definitions For jumper and connector locations, please refer to the diagrams below. Figure 4 Jumper and Connector Locations KEEX-8100 Series Use r’s Manual... -
Page 22: Jumper Settings
Status 1-2 Open Normal Operation 1-2 Short Clear ME Registers Pitch:2.54mm [Y IMTEX 3321*02SAGR(6T)] Table 5 JP3 RTC Reset Selection Jumper Status 1-2 Open Normal Operation 1-2 Short Clear RTC CMOS Pitch:2.54mm [Y IMTEX 3321*02SAGR(6T)] KEEX-8100 Series Use r’s Manual... -
Page 23: Table 6 Jp4 Backlight Power Enable Selection For Lvds1
S4 & S5 state (Default) USB power is always supply. Table 10 JP8 MPCIE1 / MPCIE2 mSATA / mPCIE Selection Jumper Setting Status MPCIE1 mSATA Selected (Default) MPCIE1 mPCIE Selected MPCIE2 mSATA Selected (Default) MPCIE2 mPCIE Selected KEEX-8100 Series Use r’s Manual... -
Page 24: Rear Panel Pin Assignments
Connector Signal Nam e Signal Nam e +USBVCC * USB_RX- USB_D- USB_RX+ USB_D+ USB_TX- USB_TX+ USB3.0 Receptacle, 30u” Au Plated, Blue, Tray [WIN WIN WDU3R-18F3B4PBUW3] *：The power source of +USBVCC can be selected by JP7 KEEX-8100 Series Use r’s Manual... -
Page 25: Table 13 Cn9 Gbe Lan1 Rj-45 Connector
Signal Name TMDS Data2+ Ground TMDS Data2– TMDS Data1+ Ground TMDS Data1– TMDS Data0+ Ground TMDS Data0– TMDS Clock+ Ground TMDS Clock– Reserved Reserved DDC_CLK DDC_DATA Ground +5 V Power Hot Plug Detect [ARGOSY HDMIV-A1915-DK2R] KEEX-8100 Series Use r’s Manual... -
Page 26: Table 16 Dvi1 Dvi-I Connector
Chapter 3 Table 16 DVI1 DVI- I Connector Signal Signal Signal TX2- TX2+ HTPLG HSYNC TX0- DDC_CLK TX0+ DDC_DATA VSYNC TX1- TX1+ TXC+ TXC- KEEX-8100 Series Use r’s Manual... -
Page 27: Main Board Pin Assignments
Serial ATA Port 1 Connector Table 18 J1 Pow er Input Connector Signal Name +12V +12V DIP 4P 2R MALE 90° Pitch:4.2mm Table 19 BAT1 CR2032 Battery Pow er Input Wafer Signal Name +VBAT Pitch:1.25mm [Pinrex 712-73-02TWR0] KEEX-8100 Series Use r’s Manual... -
Page 28: Table 20 Cn1 Sata Hdd Power Output Wafer
Pitch:1.25mm [Pinrex 712-73-06TWB0] Table 23 CN5 USB2.0 Port 10, 11 Pin Header Signal Name Signal Name +USBVCC +USBVCC USB_A- USB_B- USB_A+ USB_B+ Pitch:2.54mm [YIMTEX 3362*05SANGR-09] *：The power source of +USBVCC can be selected by JP7 KEEX-8100 Series Use r’s Manual... -
Page 29: Table 24 Cn7 Usb3.0 Port 3,4 Box Header
Signal Name Signal Name MIC_IN_L MIC_IN_R MIC_IN_JD LINE_IN_L LINE_IN_R LINE_IN_JD LINE_OUT_L LINE_OUT_R LINE_OUT_JD Pitch:2.54mm [PINREX 212-92-06GB01] Table 26 CN11 Right Channel 2W Audio A MP Output Wafer Signal Name Speaker+ Speaker- Pitch:2.0mm [Y IMTEX 503PW1*02STR] KEEX-8100 Series Use r’s Manual... -
Page 30: Table 27 Cn12 Left Channel 2W Audio Amp Output Wafer
BL_ADJ_VOL * +5V / +12V ** +5V / +12V ** BL_EN*** Pitch:1.25mm [YIMTEX 501MW1 X07MTR-1R] *：BL_ADJ can be setting in BIOS setup. **：Backlight Power can be selected by JP5. ***：BL_EN can be selected by JP4. KEEX-8100 Series Use r’s Manual... -
Page 31: Table 30 Dimm1 Ddr3 Memory So-Dimm Socket
Note：Internal Buzzer is enabled w hen Pin6-8 is shorted. Table 34 FP2 Front Panel 2 Pin Header Signal Signal Power LED + Power Button + Power Button - Power LED - SMBALERT# BATLOW# SMBus Data SMBus Clock Pitch:2.54mm [Y IMTEX 3362*05SANGR] KEEX-8100 Series Use r’s Manual... -
Page 32: Table 35 Lvds1 Primary 24-Bit, 2-Channel Lvds Panel Connector
SMB_CLK PETn0 SMB_DATA PETp0 Ground Ground USB_D- Ground USB_D+ +3.3VSB Ground +3.3VSB LED_WWAN# Ground LED_WLAN# Reserved LED_WPAN# Reserved +1.5V Reserved Ground Reserved +3.3VSB MINI PCI-Express Connector, H:9.9mm, 10u Gold Plating, T ape Reel [FOXCONN AS0B226-S99Q-7H] KEEX-8100 Series Use r’s Manual... -
Page 33: Table 37 Mpcie2 Mini-Pcie Express V1.2 Socket (Full Size)
+1.5V Reserved Ground Reserved +3.3VSB MINI PCI-Express Connector, H:5.6mm, Gold Flash, T ape Reel [FOXCONN AS0B221-S56Q-7H] *：These pins are connected to CN3 directly. Table 38 SATA1 Serial ATA Port 0 Connector Signal Name [FOXCONN LD1807V-S52U] KEEX-8100 Series Use r’s Manual... -
Page 34: Table 39 Serial Ata Port 1 Connector
Chapter 3 Table 39 Serial ATA Port 1 Connector Signal Name [FOXCONN LD1807V-S52U] KEEX-8100 Series Use r’s Manual... -
Page 35: Chapter 3 System Installation
Hold the SO-DIMM with its notch aligned with the memory socket of the board and insert it at a 30-degree angle into the socket. Figure 6 Align the SO-DIMM Me mory Module with the onboard socket KEEX-8100 Series Use r’s Manual... -
Page 36: Figure 7 Press Down On The So-Dimm Memory Module To Lock It In Place
SO-DIMM. Lift it out of the socket. Make sure you store the SO-DIMM in an anti-static bag. The socket must be populated with memory modules of the same size and manufacturer. KEEX-8100 Series Use r’s Manual... -
Page 37: Chapter 4 Ami Bios Setup
This chapter provides a description of the AMI BIOS. The BIOS setup menus and available selections may vary from those of your product. For specific information on the BIOS for your product, please contact Quanmax. NOTE: The BIOS menus and selections for your product may vary from those in this chapter. -
Page 38: Main Menu
F3: Optimized Defaults Frequenc y 1600 MHz F4 Save & Exit Sys tem date [Mon 12/01/2014] ESC Exit Sys tem ti me [15:03:02] Access Level Admi nistrator Version 2.15.1236. C opyright (C) 2012, American M egatrends, Inc. KEEX-8100 Series Use r’s Manual... -
Page 39: Advanced Menu
Version 2.15.1236. C opyright (C) 2012, American M egatrends, Inc. Onboard LAN 1 Controller Options: Disabled, Enabled Onboard LAN 1 Boot Options: Disabled, Enabled Onboard LAN 2 Controller Options: Disabled, Enabled Onboard LAN 2 Boot Options: Disabled, Enabled Audio Controller Options: Disabled, Enabled KEEX-8100 Series Use r’s Manual... -
Page 40: Table 42 Advanced Menu - Display Configuration
Options:32M, 64M, 96M, 128M, 160M, 192M, 224M, 256M, 288M, 320M, 352M, 384M, 416M, 448M, 480M, 512M, 1024M DVMT Total Gfx Mem Options: 128M, 256M, MAX IGFX – Boot Type Options: VBIOS Default, CRT,DP1, LVDS1, HDMI, DP 2 Active LVDS Options: Disabled, Enabled KEEX-8100 Series Use r’s Manual... -
Page 41: Table 43 Advanced Menu -Power Management Configuration
Options: Power Off, Power On, Last State Power Saving Mode Options: Disabled, EUP Enabled , DeepSx Enabled Resume By PCIE Device Options: Disabled, Enabled Resume By RTC Alarm Options: Disabled, Enabled Watchdog Timer Configuration Options: Disabled, EUP Enabled , DeepSx Enabled KEEX-8100 Series Use r’s Manual... -
Page 42: Table 44 Advanced Menu -Cpu Advanced Configuration
Options: Disabled, Enabled Active Processor Cores Options: All, 1,2,3 Limit CPUID Maximum Options: Disabled, Enabled Execute Disable Bit Options: Disabled, Enabled Intel ® Virtualization Tech Options: Disabled, Enabled Intel ® TXT(LT) Support Options: Disabled, Enabled KEEX-8100 Series Use r’s Manual... -
Page 43: Table 45 Advanced Menu -Amt Configuration
F1: General H elp F2: Previous Values Current Status Information F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.15.1236. C opyright (C) 2012, American M egatrends, Inc. Security De vice Support Options: Disabled, Enabled KEEX-8100 Series Use r’s Manual... -
Page 44: Table 47 Advanced Menu -Sata Configuration
Version 2.15.1236. C opyright (C) 2012, American M egatrends, Inc. SATA Controller(s) Options: Disabled, Enabled SATA Mode Selection Options: IDE, AHCI, R AID SATA Controller Speed Options: Default, Gen 1, Gen 2, Gen 3 Port Options: Disabled, Enabled KEEX-8100 Series Use r’s Manual... -
Page 45: Table 48 Advanced Menu - Intel Rapid Start Technology
+- Change Opt. F1: General H elp F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.15.1236. C opyright (C) 2012, American M egatrends, Inc. Intel Rapid Start Technology ® Options: Disabled, Enabled KEEX-8100 Series Use r’s Manual... -
Page 46: Table 49 Advanced Menu -Usb Configuration
Version 2.15.1236. C opyright (C) 2012, American M egatrends, Inc. Legacy USB Support Options: Disabled, Enabled, Auto USB 3.0 Support Options: Disabled, Enabled XHCI hand-off Options: Disabled, Enabled EHCI hand-off Options: Disabled, Enabled USB Mass Storage Driver Support Options: Disabled, Enabled KEEX-8100 Series Use r’s Manual... -
Page 47: Table 50 Advanced Menu -Dio Configuration
DI_1 F2: Previous Values DI_2 F3: Optimized Defaults DI_3 F4 Save & Exit DI_4 ESC Exit DO_1 DO_2 DO_3 DO_4 Version 2.15.1236. C opyright (C) 2012, American M egatrends, Inc. User Configuration Options: Disabled, Enabled KEEX-8100 Series Use r’s Manual... -
Page 48: Table 51 Advanced Menu - Super Io Configuration
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; Serial Port Type Options: RS232, RS422, RS485 KEEX-8100 Series Use r’s Manual... -
Page 49: Table 53 Ad Vanced Menu -Super Io Configuration - Serial Port
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; Serial Port Type Options: RS232, RS422, RS485 KEEX-8100 Series Use r’s Manual... -
Page 50: Table 54 Advanced Menu -H/W Monitor
CPU Warning Temperature Options: Disabled, 80, 85, 90, 95 Smart FAN Configuration CPU FAN Setting [Manual Mode] Options: Manual Mode, Smart Mode Manual Duty 255 FAN Setting [Manual Mode] Options: Manual Mode, Smart Mode Manual Duty 255 KEEX-8100 Series Use r’s Manual... -
Page 51: Boot Menu
Options: Disabled, Enabled CSM Support Options: Disabled, Enabled Boot Option Filter Options: UEFI and Legacy, Legacy only, UEFI only DIMM Voltage Warning Options: Disabled, Enabled Boot Option #1 Options: P1: Sandisk SSD U110 64GB, Disabled KEEX-8100 Series Use r’s Manual... -
Page 52: Security Menu
The pass word l ength must be in the followi ng range: F3: Optimized Defaults Minimum Length F4 Save & Exit Maxi mum length ESC Exit Admi nistrator Pass word User Pass word Version 2.15.1236. C opyright (C) 2012, American M egatrends, Inc. KEEX-8100 Series Use r’s Manual... -
Page 53: Save & Exit Menu
Save C hanges +- Change Opt. Discard Changes F1: General H elp Restore Defaults F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.15.1236. C opyright (C) 2012, American M egatrends, Inc. KEEX-8100 Series Use r’s Manual... - Page 54 Load Optimal Default values for all the setup values. This option allows you to load failsafe default values for each of the parameters on the Setup menus, which will provide the most stable performance settings. The F8 key can be used for this operation. KEEX-8100 Series Use r’s Manual...
-
Page 55: Chapter 5 Driver Installation
You can download the drivers for the KEEX-8100 from the Quanmax website at www.quanmax.com and install as instructed there. For other operating systems, please contact Quanmax. - Page 56 RetVal=inp(0x539);//IO Port: 0x539 RetVal=(RetVal&0x8F);//DO_1 is bit 4 //DO_2 is bit 5 //DO_3 is bit 6 outp(0x539,RetVal); RetVal=inp(0x53B);//IO Port: 0 x53B RetVal=(RetVal&0xFE);//DO_4 is bit 0 outp(0x53B,RetVal); system("pause"); //Setting DO_1~4 RetVal=inp(0x539);//IO Port: 0x539 RetVal=(RetVal|0x70);//DO_1 is bit 4 KEEX-8100 Series Use r’s Manual...
- Page 57 RetVal=inp(0x53B);//IO Port: 0 x53B RetVal=(RetVal|0x01);//DO_4 is bit 0 outp(0x53B,RetVal); system("pause"); //Reading DI_1~4 RetVal=inp(0x50C);//IO Port: 0x50C RetVal=(RetVal&0x3C);//DI_1 is bit 2 //DI_2 is bit 3 //DI_3 is bit 4 //DI_4 is bit 5 printf("DI_= %d\n",RetVal); system("pause"); return 0; KEEX-8100 Series Use r’s Manual...
-
Page 58: Watchdog Timer Sample Code
//(0xF5 bit3(0: 1sec, 1: 60 sec) of watchdog timer by setting this bit) outp(0x2E,0xF5); value=inp(0x2F); outp(0x2F,(value & 0xF7));//set unit sec. //Set Timer Value(0xF6 Time of watchdog timer) outp(0x2E,0xF6); outp(0x2F,0x14);//set to 20 sec (0x14) //Enable WDT outp(0x2E,0xF5); value=inp(0x2F); outp(0x2F,(value | 0x30));// KEEX-8100 Series Use r’s Manual... - Page 59 Appendix B outp(0x2E,0xF0); outp(0x2F,0x81);//bit7 WDTRST# output is enabled return 0; KEEX-8100 Series Use r’s Manual...
