LAN ports
The LAN ports require Category (CAT) 3, CAT 5e, or CAT 6a
unshielded twisted pair (UTP) or shielded twisted pair (STP) cables,
crossover or patch cables.
The cable used depends on your network speed. The switcher LAN
port supports both 10 Mbps (10Base-T — Ethernet) and 100 Mbps
(100Base-T — Fast Ethernet), half-duplex and full-duplex Ethernet
connections.
10Base-T Ethernet requires CAT 3 UTP or STP cable at
•
minimum.
100Base-T Fast Ethernet requires CAT 5e UTP or STP cable at
•
minimum.
For ports on an IPCP module, see the IPCP Pro Series User Guide
at
www.extron.com
conigure and operate the IPCP control processor.
DTP and Expansion ports
The DTP input and output ports are compatible with Extron
XTP DTP 24 SF/UTP cables or shielded twisted pair (F/UTP,
SF/UTP, and S/FTP) cable. The Expansion port requires CAT 5e, 6,
6a, or 7 shielded twisted pair cable.
For the Expansion port only —
ATTENTION:
Connect this port to the Expansion port on a compatible
•
Extron DMP processor. Do NOT connect this port to a LAN
or Power over Ethernet port; equipment damage can occur.
Connectez ce port au port d'expansion sur un processeur
•
DMP d'Extron compatible. Ne connectez PAS ce port à un
port LAN ou d'alimentation via Ethernet ; le matériel pourrait
être endommagé.
For the DTP ports only —
Extron recommends the following practices to achieve full
transmission distances up to 330 feet (100 m) and reduce
transmission errors.
Use the following Extron XTP DTP 24 SF/UTP cables and
connectors for the best performance:
XTP DTP 24/1000 Non-Plenum 1000' (305 m) spool
XTP DTP 24P/1000 Plenum 1000' (305 m) spool
XTP DTP 24 Plug Package of 10
to make all network connections and to
DTP CrossPoint 4K Series • Installation
22-236-03
22-235-03
101-005-02
13
