S y n t a x
S y n t a x
Parameter
view
enable[0/1]
traceable/ untraceable
-v
-e
AP_INDEX
CLASS
-d
show_config [-t |–u]
E x a m p
E x a m p
> appqos enable 1
APP QoS set to Enable.
> appqos traceable -e 68 2
TELNET: ENABLED, QoS Class 2.
Vigor2120 Series User's Guide
D e s c r i p t i o n
D e s c r i p t i o n
Description
It means to display current status of APP QoS.
It means to enable or disable the function of APP QoS.
The APPs are divided into traceable and untraceable based on
their properties.
It means to view the content of all traceable APs.
Use "appqos traceable –v" to display all of the traceable APS
with speficed index number.
Use "appqos untraceable –v" to display all of the untraceable
APS with speficed index number.
It menas to enable QoS for application(s) and assign QoS
class.
Each index number represents one application.
Index number: 50, 51, 52, 53, 54, 58, 60, 62, 63, 64, 65, 66,
68 are used for 13 traceabel APPs.
Index number: 0~49, 55~59, 61, 67, 69, and 70~123 are used
for 125 untraceable AP.
Specifies the QoS class of the application, from 1 to 4
1:Class 1, 2:Class 2, 3:Class 3, 4:Other Class
It means to disable QoS for application(s).
It means to display all of the traceable/untraceable APs and
the configuration.
l e
l e
