INDEX
-v
-n NAME
CHK
-s CHK [START_P]
[END_P]
-d CHK [START_P]
[END_P]
E x a m p l e
E x a m p l e
> object service obj 1 -n limit
> object service obj 1 -p 255
> object service obj 1 -s 1 120 240
> object service obj 1 -d 1 200 220
> object service obj 1 -v
Service Object Profile 1
Name :[limit]
Protocol:[255]
Source port check action:[!=]
Source port range:[120~240]
Destination port check action:[!=]
Destination port range:[200~220]
It means the index number of the specified service object
profile.
It means to view the information of the specified service
object profile.
Example:
object service obj 1 -v
It means to define a name for the IP object.
NAME: Type a name with less than 15 characters.
Example:
object service obj 9 -n bruce
It means the check action for the port setting.
0=equal(=), when the starting port and ending port values are
the same, it indicates one port; when the starting port and
ending port values are different, it indicates a range for the
port and available for this service type.
1=not equal(!=), when the starting port and ending port
values are the same, it indicates all the ports except the port
defined here; when the starting port and ending port values
are different, it indicates that all the ports except the range
defined here are available for this service type.
2=larger(>), the port number greater than this value is
available..
3=less(<), the port number less than this value is available for
this profile.
It means to set souce port check and configure port range
(1~65565) for TCP/UDP.
END_P, type a port number to indicate source port.
Example:
object service obj 3 -s 0 100 200
It means to set destination port check and configure port
range (1~65565) for TCP/UDP.
END_P, type a port number to indicate destination port.
Example:
object service obj 3 -d 1 100 200
