For Dial-In
<index>
<name>
<ip>
<usr> <pwd>
<key>
<nip> <nmask>
E E x x a a m m p p l l e e
> vpn setup 1 name1 dialin 1.2.3.4 vigor 1234 abc 192.168.1.0
255.255.255.0
% Profile Change Log ...
% Profile Index : 1
% Profile Name : name1
% Username : vigor
% Password : 1234
% Pre-share Key : abc
% Call Direction : Dial-In
% Type of Server : ISDN PPTP IPSec L2TP
% Dial from : 1.2.3.4
% Remote NEtwork IP : 192.168.1.0
% Remote NEtwork Mask : 255.255.255.0
>
e.g.,,
vpn setup 1 name1 l2tp_out 1.2.3.4 vigor 1234 192.168.1.0
255.255.255.0
It means the index number of the profile.
It means the name of the profile.
It means the IP address allowed to dial in.
It means the user and the password required for the
PPTP/L2TP connection.
It means the value of IPsec Pre-Shared Key.
It means the remote network IP and the mask.
e.g.,
vpn setup 1 name1 dialin 1.2.3.4 vigor 1234 abc 192.168.1.0
255.255.255.0
