Index
Status
You can set up to 15 schedules. Then you can apply them to your Internet Access or VPN
and Remote Access >> LAN-to-LAN settings.
To add a schedule:
1. Click any index, say Index No. 1.
2. The detailed settings of the call schedule with index 1 are shown below.
Available settings are explained as follows:
Item
Enable Schedule
Setup
Start Date
(yyyy-mm-dd)
Start Time (hh:mm)
Duration Time
(hh:mm)
Action
Click the number below Index to access into the setting
page of schedule.
Display if this schedule setting is active or inactive.
Description
Check to enable the schedule.
Specify the starting date of the schedule.
Specify the starting time of the schedule.
Specify the duration (or period) for the schedule.
Specify which action Call Schedule should apply during the
period of the schedule.
Force On -Force the connection to be always on.
Force Down -Force the connection to be always down.
Enable Dial-On-Demand -Specify the connection to be
dial-on-demand and the value of idle timeout should be
specified in Idle Timeout field.
Disable Dial-On-Demand -Specify the connection to be up
when it has traffic on the line. Once there is no traffic over
idle timeout, the connection will be down and never up
again during the schedule.
255
Vigor2120 Series User's Guide
