Available settings are explained as follows:
Item
Multi-VLAN Channel
(3~5)
WAN Type
General Settings
Description
Enable – Click it to enable the configuration of this
channel.
Disable –Click it to disable the configuration of this
channel.
The connections and interfaces created in every channel
may select a specific WAN type to be built upon. In the
Multi-VLAN application, only the Ethernet WAN type is
available. The user will be able to select the physical WAN
interface the channel shall use here.
VLAN Tag – Type the value as the VLAN ID number.
Valid settings are in the range from 1 to 4095. The network
