3.
Product Components and Accessories (cont.)
- This USB socket is for connection to a PC when using the optional MMS2
D
logging software.
C
Figure 1: Connections for Probes and Sensors
•
The Hygrostick (POL4750), Quikstick (POL8750) and Short Quikstick
(POL8751) probes measure relative humidity (%RH) and ambient air
temperature in rooms or materials. They can be connected to the MMS2
instrument either directly or by means of the extension lead.
•
The surface temperature sensor is used when investigating condensation
situations.
•
The moisture probe is used to obtain percent moisture content values in
wood or wood moisture equivalent (WME) values in other non-
conductive materials.
•
Multiple probe types are available, including hammer probes and deep
wall probes.
INS8800 Rev. D
B
Non-contact Surface Temperature Sensor (IR)
Protimeter MMS2 Instruction Manual
Search Mode Sensor
A
Laser
D
3
