Getting Started
2.3.2 Option 2: Code Composer Studio™ IDE (CCS)
2.3.2.1 Download and Install
Download and run the Code Composer Studio IDE version 6.1.1 or newer (CCS) installation wizard from
http://processors.wiki.ti.com/index.php/Download_CCS. Online and offline installation options are
available. If any issues occur with the online installer, then try the offiline installer instead. Use the default
installation options up until Processor Support (see
MSP Ultra Low Power MCUs for processor support. Additional processor support can be added based on
preferred disk usage. Follow the remaining installation instructions in the wizard to complete the
installation process.
2.3.2.2 Import and Configure Project
To use Code Composer Studio IDE version 6.1.1 to flash the NFCLink Standalone firmware to the MSP-
EXP430F5529LP, follow these steps:
1. Open Code Composer Studio IDE.
2. Go to Project → Import CCS Projects...
3. Click Browse and select the directory: [Installed Path]\examples\boards\MSP-
EXP430F5529LP\F5529LP_TRF7970A_ALL_NFC_MODES.
4. Import the F5529LP_TRF7970A_ALL_NFC_MODES project (see
5. Select the imported project in the Project Explorer window and then click the debug icon
the project and download the example firmware to the device.
6. Click the terminate button
7. Cycle the power to the LaunchPad development kit by unplugging the USB cable and then plugging it
back in.
8. The firmware on the LaunchPad development kit now operates in stand-alone mode and reads
NFC/RFID tags by default.
6
NFCLink Standalone Getting Started
Figure 3. Code Composer Studio™ IDE Installation
in the debugging window.
Copyright © 2016, Texas Instruments Incorporated
Figure 3). The minimum requirement is to select only
Figure 4).
