Page 1: User Manual
FOS 12R Hybrid User Manual Beam Congratulations on purchasing this 280W moving Light Thank you for extending your trust in our technology! - Page 2 FOS 12R Hybrid Voltage : 110W~240V/50-60Hz Lamp : OSRAM 280W Power consumption: 470W Lens : high precision optical lens Color wheel: 13 dichroic filters + white Rotating Gobo Wheel, with 9 bidirectional and indexable gobos (outside diameter: 15,4 mm, image diameter: 13 mm)
- Page 3 When not using the product, and proform to cleaning always disconnect the product from mains! To do so, hold the mains plug by the handling surface and never pull the mains cord! Never connect the device to dimmer packer! 3. Housing ATTENTION ： FOS Technologies - 3 DANGER OF LIFE！RISKOF FIRE！ RISK OF SHORT CIRCUIT！ 2/11...
- Page 4 FOS Technologies - 4 acceptance test at least every four years.
- Page 5 Before cleaning,always disconnect the product from mains! FOS Technologies - 5 This product should be cleaned with a moist cloth only;never use aggressive cleaning agents,solvents or benzine 4/11...
-
Page 6: Menu Setting
Back back to the last menu Zero Advanced Adjustment Management Back Reset esume to factory setting Manually Save Save changed setting Controlled Back Back to main menu Light Reset All Motor All motor Self-Test FOS Technologies - 6 5/11... -
Page 7: Information Search
Back to last step save save changed date back Back to main menu hand controlled for lamp Hand controlled on/off Lamp default lamp on choose channel FOS Technologies - 7 LAMP 6/11... -
Page 8: Dmx Chart
Deep blue proportional 22-31 Yellow proportional 31-40 Green proportional 40-49 Magenta proportional 49-58 Light Yellow proportional 58-67 Light red proportional 67-76 Deep Yellow proportional 76-85 Pink proportional 85-94 Light Blue proportional 94-103 Light Green proportional FOS Technologies - 8 7/11... - Page 9 Gobo9 step 58-63 Gobo10 step 64-69 beam reducer 1 70-75 beam reducer 2 76-81 beam reducer 3 Shaking gobos from slow to fast 88-95 Gobo1 96-103 Gobo2 104-111 Gobo3 112-119 Gobo4 120-127 Gobo5 128-135 Gobo6 FOS Technologies - 9 8/11...
- Page 10 92-99 Gobo5 channel 12 100-107 Gobo6 108-115 Gobo7 116-123 Gobo8 124-129 Gobo9 130-137 Gobo1 138-145 Gobo2 146-153 Gobo3 154-161 Gobo4 Rotation - set rotation on channel 12 162-169 Gobo5 170-177 Gobo6 178-185 Gobo7 186-193 Gobo8 FOS Technologies - 10 9/11...
- Page 11 248-255 Macro 7 Prism rotation and indexing Frost 0-64 open 65-255 Frost from 0% to 100% ZOOM 0-255 Zoom from max. to min.beam angle 0-255 Zoom fine 0-255 Focus 0-255 Focus fine 0-255 open FOS Technologies - 11 Shutter/Strobe 10/11...
- Page 12 Shutter open 128-143 From fast to slow 144-159 from slow to fast 160-191 Open 192-223 Random strobe-effect from slow to fast 224-255 Shutter open, Full lamp power Dimmer 0-255 Dimmer intensity from 0% to 100% FOS Technologies - 12 11/11...
