- Page 1 FOS ACL Line 12 This manual contains important information. Please read before operating fixture.
-
Page 2: Security Tips
1. SECURITY TIPS WARNING!!! To reduce the risk of fire, electric shock, or injury to persons, follow these important safety instructions: non-professionals, not to disassemble the light arbitrarily and lighting accessories inside. rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ (to be selected). - Page 3 2 TECHNOLOGY REFERENCE Power Supply: AC 100-240V/50-60Hz Power consumption:370 W Light source: 12pcs*30w LED RGBW 4in1 mixing color Beam Angle: 3 degree Dimmer: 0-100% dimmer Strobe rate:0-20HZ Working Environment: -20℃-40℃ IP rate: IP20 DMX Channels: 13/53 CH Control Mode: DMX512, Master-slave,Sound,Auto Build-in programs Independent control of each LED Control panel: LCD display...
-
Page 4: Display Details
3 Board Instruction Operate Menu Display Details Sub Menu / Options A001-A512 001 - 512 Address System Run Mode DMX, Sound, Auto Setup Fixture ID DMX Ch Mode 13 Ch or 53 Ch No Signal Clean / Keep Language En / Cn Load Default Check Manual Control of each... -
Page 5: Dmx Channel Sheet
4 DMX CHANNEL SHEET 13CH Function DMX Value Function Tilt 0 - 255 Tilt movement Tilt Fine 0 – 255 16bit tilt movement Tilt Speed 0 – 255 Movement speed Dimmer 0 – 255 Linear intensity Strobe 0 – 3 Shutter Open 4 –... -
Page 6: Fixed Equipment
Strobe 0 – 3 Shutter Open 4 – 255 Strobe from slow to fast Red 1 0 – 255 Red 1 intensity Green 1 0 – 255 Green 1 intensity Blue 1 0 – 255 Blue 1 intensity White 1 0 –... -
Page 7: Maintenance
Please connect XLR-XLR control wire with every light from the output of DMX. XLR connection : ATTENTION: Please do remember to connect one circle circuit plug on the output signal of last equipment. And this circle circuit plug was connected a 120ohm resistance between terminals 2 and 3 of the CANON plug, connect this circle circuit plug can avoid the signal flash phenomena of signal DMX512 during the transmission. -
Page 8: After Service
No DMX input 1. If the polarity is opposited in the 1. Correct the DMX DMX controller. polarity. 2. If it is in DMX mode. 2. Change to the DMX mode. 3. If there are 2 Master in a loop. 3. - Page 9 Warranty Card Name Model Production Purchase Sale Store End User Link man: Company Name: Tel: Stamp Add: Description: These must be truthfully fill, seal by the end-user and point-of-sale, or else the warranty will not work (warranty period and terms, see the following) warranty period：one year since purchase warranty terms：1、If fail when using the product in normal state, you can made under the provisions of the warranty, show the warranty card and...
