To remove the circuit board from the enclosure
Caution:
!
Attention: Always hold circuit boards by the edges to prevent damage from static
1. Remove the 4 screws and then remove the display.
2. Insert a flathead screwdriver under the tabs on the enclosure, shown in Figure 2, in order
to lift the tabs and remove the base.
Figure 2
10 (40)
Risk of Electric Shock. Disconnect the mains power and disconnect the
controller from all wiring before opening the enclosure.
electricity. Always wear an anti-static bracelet when handling circuit
boards.
Tabs on enclosure
