3. Hold the circuit board with one hand, and with the other hand lift the tabs so that you can
remove the circuit board from the enclosure. See Figure 3.
Circuit board
Figure 3
!
Attention: Be careful not to break the tabs. Do not apply excessive force.
Lift tabs and remove circuit board
Installation
Lift tabs and remove
circuit board
11 (40)
