Field wiring

i
Note:
4.1

To Wire the Terminals

Figure 4 on page 12 shows the location of the terminals. The terminals are depluggable for
ease of wiring.

4.1.1 Required Tools

Tools needed:
• Precision or jeweler's screwdriver set
• Wire cutter
• Wire stripper

4.1.2 Installation Tips

• Perform visual inspection of circuit board and parts for obvious issues.
• Use a wire tie to group wires for easy identification and neatness.
4.2

Power Supply Connection

• 24 Vdc, 400 mA max.
• 24 Vac, 500 mA max.
Installation of OpenBAS-LC-NX12R controllers must be in accordance with the
Canadian Electrical Code or the National Electrical Code, and comply with all
local regulations. Final acceptance is subject to the Local Authority Having
Jurisdiction (AHJ).
