NOTE:
1. For C8000-DFFFF option-ROM on PCI BIOS,
BIOS will automatically enable the shadow
RAM. User does not have to select the item.
2. IDE second channel control:
Enable : enables secondary IDE port and BIOS,
and assigns IRQ15 for this port.
Disable: disables secondary IDE port and
IRQ15 for availability to other device. The
item is optional only for PCI BIOS.
(
