Internal - Ecom J2KN pro Operation Manual

12.1 Internal (continued)
USB
For DASNT 5:
For Advanced DAS:
Bluetooth
For DASNT 5:
For Advanced DAS:
Pitot factor
Set the Pitot factor for flow rate calculation. If the flow rate
calculation is not needed, set Pitot factor to 0. If you are using
a standard ECOM probe, set this to 0.93. (For more information
on the flow measurement option, see 17. Flow Measurement
with Pitot Tube.)
Printout
This feature allows you to add 8 lines of text at the bottom of
the printout (20 characters per line). Usually this is reserved for
company information such as company name, address, phone
number, and website. (To add a special note for a specific test,
please see 8.2 Printing.)
To change printout text, press Up/Down to select the line you
would like to edit. Press F4 to toggle up and down between the
insert text box and the alphanumeric grid. Using the directional
keys and OK, select the characters to insert text. Press F3 to
change grid to lower case, numbers, or other characters. To
delete a character, press F4 to toggle up, then F2 to delete.
Press F1 to accept text and continue to the next line.
Set Baud rate to 1200
Set Protocol to Enhanced
Set Baud rate to 38400 and
Set Protocol to Enhanced
Set Baud rate to 9600
Set Protocol to Enhanced
Set Baud rate to 9600 and
Set Protocol to Enhanced
The first time you connect to a computer
via Bluetooth, use "1234" pairing PIN.
Page 23
