• EDID Minder — automatically manages EDID communication between connected
devices ensuring that the source powers up properly and reliably outputs content for
display.
• HDCP compliant
• Key Minder continuously verifies HDCP compliance — Key Minder authenticates and
maintains continuous HDCP encryption between all input and output devices to enable
simultaneous distribution of a single source signal to two, four, or six displays.
• HDCP Visual Confirmation — provides a full-screen green signal is sent when
HDCP-encrypted content is transmitted to a non-HDCP compliant display, providing
immediate visual confirmation that protected content cannot be viewed on the display.
• Automatic input cable equalization — up to 25 feet (7.62 meters) when used with
Extron HDMI Pro Series cable. Actively conditions incoming HDMI signals to compensate
for signal loss when using long cables, low quality cables, or source devices with poor
signal output.
• Automatic color bit depth management — The DA HD 4K Series automatically adjusts
color bit depth based on the display EDID, preventing color compatibility conflicts between
source and displays.
• HDMI to DVI Interface Format Correction — Automatically reformats HDMI source
signals for output to a connected DVI display.
•
Output muting via RS‑232 or USB port — Provides the capability to mute one or all
outputs at any time. This allows content to be viewed on a local monitor prior to appearing
on the main presentation display.
•
HDCP authentication and signal presence LED indicators — Front-panel LED
indicators for signal presence and HDCP authentication provide real-time feedback and
monitoring of key performance parameters.
•
Easy setup and commissioning with Extrons Product Configuration Software
(PCS) — Conveniently configure multiple products using a single software application.
• Easy mounting options — The DA2 HD 4K features a 1 inch (2.5 cm) high, quarter rack
width enclosure. The DA4 HD 4K and DA6 HD 4K feature a 1U high, half rack width
enclosure. All three products can be conveniently mounted in standard racks or under
furniture.
•
Includes LockIt HDMI cable lacing brackets
secure HDMI cables connected to the HDMI input and output connectors, preventing
accidental disconnection of the cables.
•
Provides +5 VDC, 250 mA power on each output for external peripheral devices.
•
Worldwide power compatibility — The DA2 HD 4K includes an energy-efficient external
universal power supply. The DA4 HD 4K and DA6 HD 4K are equipped with an
100-240 VAC, 50/60 Hz, internal universal power supply.
— LockIt lacing brackets are used to
DA HD 4K Series • Introduction 2
