BDI cavo Assembly Instructions

Component List
Designed by Matthew Weatherly.
These distinctive product configurations are protected by US and
international patents, trade dress, and/or copyright laws.
BDI are trademarks of Becker Designed, Inc.
All Rights reserved. ©2013, BDI
Made in China. 8167_8168REV10252013v2
cavo
8167 8168
and
A - Phillips Screwdriver
x 1
B - Hex Driver
x 1
C - Cabinet
x 1
D - 1/4-20 x 5/8"
Machine Screw
x 10
E - Stretcher
x 1
F - Leg
x 2
G - 1/4-20 x 1.75"
Machine Screw
8167 x 4
8168 x 3
H - M4 x 25mm
Machine Screw
8167 x 2
8168 x 4
I - Pull
8167 x 1
8168 x 2
J - Adjustable Shelf
8168 x 2
K - Back Panel x 2
L - Cardboard Corner
Protector
x 2
a s s e m b l y
.
bdiusa com
Cavo is engineered for easy assembly. Carefully follow this
procedure to prevent any damage.
Please do not discard packaging until reading
these instructions.
NOTE: This instruction sheet is intended for
the Cavo collection; model 8168 is shown for
illustration.
Placement and Maintenance
Cavo is designed for indoor use on level floors. Clean steel parts
and wood veneer with a moist cloth. Many wood surfaces are
subject to fading under direct sunlight. BDI's unique Graphite finish
has properties that make it more sensitive than others. Please avoid
placing BDI's Graphite finish in direct sunlight.
Step 1
Unpack and Identify
Unpack and identify the components at left. Note that some
components are shipped inside the cabinet. The assembly
workspace should be a non-marring surface such as clean carpet.
For missing hardware pieces, please contact BDI Customer Service
at customerservice@bdiusa.com. For all other concerns, please
contact your BDI Retailer.
Step 2
Remove Cardboard Corner Protectors (L) from packaging. Loosely
attach Stretcher (E) to Legs (F) using Screw (D).
J
B
D
F
1
i n s t r u c t i o n s
@
customerservice
E
.
bdiusa com
D
F
