BDI CASATA 2823 Assembly Instructions

BDI CASATA 2823 Assembly Instructions

Advertisement

Quick Links

C
2823, 8627
Component List
A - Assembled Cabinet
B - Flat Wrench x 1
C - Phillips Screwdriver
D - Adjustable Shelf
E - Back Panel x 2
F - Allen Wrench x 1
Leveler glides are accessible
near the bottom of the side
panels using the Flat Wrench
(B).
Designed by Cristian Wicha.
'Casata' is a trademark of Becker Designed, Inc.
All rights reserved. ©2009 Becker Designed, Inc.
Made in China. 8822782292823REV101509v8
A S A T A
8629-2
AND
Your Casata Home Theater Furniture is engineered for easy assembly.
Carefully follow this procedure to prevent any damage.
x 1
NOTE: This instruction sheet is intended for the entire Casata collection;
model 8629-2 is shown for illustration.
Placement and Maintenance
Casata Home Theater Furniture is designed for indoor use on level floors.
Clean glass with glass cleaner, and steel parts and wood veneer with a
moist cloth.
x 1
Step 1
Unpack and identify the parts listed. The assembly workspace should be a
non-marring surface such as carpet. For missing hardware pieces please
contact BDI Customer Service at customerservice@bdiusa.com. For all
Model 8627 x 3
other concerns, please contact your BDI Retailer.
Model 8629-2 x 2
Model 2823 x 3
Step 2
Leveling and Shelf Adjustment
The shelf pins located inside the left and right cabinet space may be
repositioned, allowing you to raise or lower each shelf to the desired level
using the Phillips Screwdriver (C).
A S S E M B L Y I N S T R U C T I O N S
2823
.
BDIUSA
COM
For more information about the adjustable levelers and
troubleshooting, be sure to check out "Fine tuning your
new BDI Casata Home Theater Furniture" at the end of
these instructions.
8629-2
8627
@
CUSTOMERSERVICE
BDIUSA
Shelf Pin
.
COM
1
