- Page 1 CODA 3521/3522 ™ OFFICE CHAIR INSTRUCTION MANUAL LET’S GET STARTED. DESIGNED BY CLAUDIO BELLINI...
- Page 3 Congratulations on the purchase of your Coda Office Chair 3521/3522 from BDI. Your office chair has been designed to provide a lifetime of enjoyment. This manual will provide you with assembly instructions and other helpful information to ensure you get the most out of your product.
- Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. Do not use power tools for the assembly of this product.
- Page 5 HARDWARE AND COMPONENTS Armrest (Left & Right) (C3) QTY: 1 of each Lift Column (C4) QTY: 1 Base (C5) QTY: 1 Wheel (C6) QTY: 5 Headrest (C7) QTY: 1 NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 5...
- Page 6 Seat Assembly (C2) as shown. Lift and pull the HEX WRENCH – T1 Backrest Assembly (C1) toward the Seat Assembly (C2) so the mounting holes align. Fasten using 3 Screws with Washers (H1). SCREW – H1 Tighten with 5mm Hex Wrench (T1). 6 | BDIUSA.COM CODA 3521/3522...
- Page 7 STEP 2. ATTACH ARMREST ASSEMBLY Ensuring the R and L labels on the Left and Right Armrests (C3) match the R and L labels HEX WRENCH – T1 on the Seat Assembly (C2), attach the armrests to the seat using 6 Screws (H2) and tighten with 5mm Hex Wrench (T1).
- Page 8 Seat Assembly (C2). Press into place. ASSEMBLY STEP 4. INSTALL SWIVEL WHEELS Position the Base (C5) upside down on the carpeted floor. Press the Swivel Wheels (C6) firmly into the holes until they lock. 8 | BDIUSA.COM CODA 3521/3522...
-
Page 9: Step 5. Connect The Base
STEP 5. CONNECT THE BASE ASSEMBLY Connect the Base (C5) to the chair either right side up (with base on the floor as shown) or upside down on top of the box. Insert the Column (C4) into the hole and press to fit. NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 9... - Page 10 2 Pan Head Screws x 1/2” (H3) from HEX WRENCH – T2 the bottom. This is easiest to do if the Headrest is in its highest position. Tighten with 4mm Hex Wrench (T2). SCREW – H3 10 | BDIUSA.COM CODA 3521/3522...
- Page 11 FUNCTION ADJUSTING ARMRESTS Lift the button under the arm to ADJUSTING HEADREST adjust the height. Further, refine your settings by grasping the top To position the headrest, raise it completely to of the arms and sliding in any release it, then move it to its lowest position. As direction.
-
Page 12: Warranty
WARRANTY BDI warrants to the original purchaser that this product shall be free of defects in assembly, material, or workmanship for five (5) years from the original date of retail purchase. In the event of a proven defect in this product’s assembly, material, or workmanship within five (5) years from the original date of purchase, BDI will replace any such defective part(s).
