- Page 1 COSMO 5729 ™ CONSOLE INSTRUCTION MANUAL LET’S GET STARTED. DESIGN MATTHEW WEATHERLY...
- Page 3 Congratulations on the purchase of your Cosmo Console 5729 from BDI. Your console has been designed to provide a lifetime of enjoyment. This manual will provide you with assembly instructions and other helpful information that will ensure that you get the most out of your cabinet.
- Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. Do not use power tools for assembly of this product.
- Page 5 HARDWARE AND COMPONENTS PART # PART # DESCRIPTION DESCRIPTION Back Base Frame Front Base Frame QUANTITY QUANTITY TOOL REQUIRED (NOT INCLUDED) Phillips Screwdriver PART # PART # DESCRIPTION DESCRIPTION Connector Tube Drawer Liner QUANTITY QUANTITY NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 5...
- Page 6 T1-HEX DRIVER tabs into the ends of the connector tubes. Attach (C1 & C2) Base Frames to (C3) Connector Tubes using (6) (H1) Screws. Tighten with H1-SCREW (T1) Hex Driver. C1/C2 Metal tabs No holes here 6 | BDIUSA.COM COSMO 5729...
-
Page 7: Step 2. Attach The Base
2 PERSON TASK STEP 2. ATTACH THE BASE ASSEMBLY Make sure the packing material bracing the 2 PART/DESCRIPTION inner shelves is still in place before rotating the cabinet. With help from another person, carefully position (A1) Cabinet on its back. Attach the T1-HEX DRIVER base as shown using the (4) (H1) Screws (at the corners) and (2) (H2) Screws through the (C3) - Page 8 The shelves may be positioned at any of the available locations corresponding with threaded inserts inside the cabinet by moving the Shelf Pins. Use a Phillips Driver to loosen, reposition, and re-tighten the Shelf Pins. Reposition shelf pins Level the cabinet (if needed) (if needed) Down 8 | BDIUSA.COM COSMO 5729...
-
Page 9: Fine Tuning
ADJUST DOOR HINGES—IF NEEDED FINE TUNING These steps are to be followed after you have unpacked and completed the simple assembly instructions for your Cosmo Console. Due to jostling in freight or perhaps an uneven floor, the doors on your Cosmo console may not appear to be in perfect alignment. Making a few minor adjustments can rectify this situation. - Page 10 4) Pushing the orange lever towards the moves the drawer to the left. Rotating outside wedges the drawer up. Pulling it away moves it right. towards the middle of the drawer makes the drawer drop. 10 | BDIUSA.COM COSMO 5729...
- Page 11 STEP 4. INSTALL BACK PANELS REMOVE PORCELAIN TOP—IF NEEDED FINE TUNING ASSEMBLY Your Cosmo Console features a durable, heat PART/DESCRIPTION resistant porcelain top. The top may be cleaned with mild soapy water on a damp cloth. If liquid NOT INCLUDED spills into the seam, the porcelain top may be Phillips Screwdriver removed for cleaning purposes, or may be...
- Page 12 After cleaning, re-insert the porcelain top and re-attach the 4 metal plates. To reattach the drawer, place the drawer directly on top of the metal drawer slides and slowly push the drawer all the way in until it “snaps” back on. Metal plates 2 of 4 12 | BDIUSA.COM COSMO 5729...
-
Page 13: Care And Maintenance
While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please take care to avoid positioning your BDI cabinet in any area with extensive direct sunlight. -
Page 14: Warranty
WARRANTY BDI warrants to the original purchaser that for the below stated warranty term, BDI will repair or replace any product, part, or component covered by this warranty which fails under normal use as a result of a defect in material or workmanship. BDI will repair or replace the aforementioned product, part or component with a comparable product, part or component. - Page 15 WAR N IN G SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM FURNITURE TIP-OVER. TO HELP PREVENT TIP-OVER: n Install tip-over restraint. Place heaviest items in lower compartments. n Never allow children to climb or hang on drawers, doors or shelves. n Never open more than one drawer at a time. USE OF TIP-OVER RESTRAINT MAY REDUCE—BUT NOT ELIMINATE—THE RISK OF TIP-OVER.
- Page 16 These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws. Cosmo & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2020, BDI | V.08.03.2020 Made in China.
