- Page 1 COSMO BAR 5720 ™ BAR CABINET INSTRUCTION MANUAL LET’S GET STARTED. DESIGN MATTHEW WEATHERLY...
- Page 3 Congratulations on the purchase of your Cosmo Bar 5720 from BDI. Your bar cabinet has been designed to provide a lifetime of enjoyment. This manual will provide you with assembly instructions and other helpful information that will ensure that you get the most out of your cabinet.
- Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. Do not use power tools for assembly of this product.
- Page 5 HARDWARE AND COMPONENTS PART # PART # DESCRIPTION DESCRIPTION Cabinet Lower Shelf QUANTITY QUANTITY PART # PART # PART # DESCRIPTION DESCRIPTION DESCRIPTION Base Frame Top Connector Tube Bottom Connector Tube QUANTITY QUANTITY QUANTITY PART # PART # PART # DESCRIPTION Anti-skid Panel DESCRIPTION...
- Page 6 Base Frame with holes facing down. Attach H1-SCREW connector tubes using 8 (H1) Screws. Sleeve the other (C1) Base Frame over the assembly as shown below and tighten all 16 (H1) Screws with (T1) Hex Wrench. 6 | BDIUSA.COM COSMO 5720...
-
Page 7: Step 2. Attach The Base
2 PERSON TASK STEP 2. ATTACH THE BASE ASSEMBLY With help from another person, carefully position PART/DESCRIPTION the (A1) Cabinet onto at least two layers of packing material and orient on its back as shown. T1-HEX WRENCH NOTE: the packing material creates finger space to lift the cabinet after attaching the base. - Page 8 (C5) Anti-skid Pads are centered on the end of the legs. With 2 people (1 person on each side) carefully and slowly lift the cabinet with hands placed along the edges of the cabinet indicated with arrow #2. Leg centered on anti-skid pad Lift Recommended hand positions (both sides) 8 | BDIUSA.COM COSMO 5720...
-
Page 9: Step 4. Prepare The Wall
STEP 4. PREPARE THE WALL ASSEMBLY WARNI N G DO NOT ALLOW CHILDREN TO SWING ON THE OPEN DOORS. To ensure stability, it is required that you anchor PART/DESCRIPTION your Cosmo Bar to the wall using the two (H3) Anchor Straps included. Determine the desired NOT INCLUDED location of your Cosmo Bar and then position Wall Anchor... - Page 10 Attach the (A2) Lower Shelf with 4 (H1) T1-HEX WRENCH Screws and tighten with (T1) Hex Wrench. H1-SCREW 10 | BDIUSA.COM COSMO 5720...
- Page 11 STEP 4. INSTALL BACK PANELS STEP 7. INSTALL RECHARGEABLE STRIP LIGHT ASSEMBLY ASSEMBLY Find the (H4) Rechargeable Strip Light. Using PART/DESCRIPTION the (H5) Micro HDMI/USB cable, charge the light for 6 hours. Once charged, install it onto the metal strip (it is held with magnets) located H4-STRIP LIGHT in the angled recess towards the top front of the cabinet.
-
Page 12: Fine Tuning
T2-LEVELER WRENCH Mirror Adjustable Shelf Storage Shelves for Porcelain Surface Cans and Bottles down Wine Bottle Wine Glass Level the Cabinet Reposition Shelf Pins Storage Storage (if needed) (if needed) 12 | BDIUSA.COM COSMO 5720... - Page 13 LEVEL THE UNIT & ADJUST THE DOORS—IF NEEDED FINE TUNING Check to make sure your Cosmo Bar is level. If it is not, adjust the levelers located under the front legs using (T2) Leveler Wrench. With both doors closed, check to see if the top corners of the doors align. If not, dial out the corresponding front leveler under the door that is sagging.
- Page 14 8", reach inside and find the 60mm disc just under the front center edge of the porcelain. Rotate the disc 180 degrees. Lift the porcelain out by pushing up from below. Disc Rotate Disc to Unlock Unlocked Position 14 | BDIUSA.COM COSMO 5720...
-
Page 15: Care And Maintenance
While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please take care to avoid positioning your BDI cabinet in any area with extensive direct sunlight. -
Page 16: Warranty
WARRANTY BDI warrants to the original purchaser that for the below stated warranty term, BDI will repair or replace any product, part, or component covered by this warranty which fails under normal use as a result of a defect in material or workmanship. BDI will repair or replace the aforementioned product, part or component with a comparable product, part or component.
