Installation and Reference Manual
l In Manager select Utilities then Commands
m Under the Commands list select Ask Master
n Within the Enter IP Address field enter the IP Address of the Primary Call Server, eg 192.168.0.1
o Click on the Set Master button
4 On the Primary Call Server:
a In Manager select Unassigned Modules.
b Select the new Call Server, eg Secondary Call Server
c From the Module Status list box select Member.
d Select Update or Apply when ready
e Select Modules.
f Select the Secondary Call Server, select the Call Server page and note that the Administration
Mode is set to Secondary.
5 On the Secondary Call Server
a In Manager select the WAN Links.
b Select the Secondary Call Server and select WANLink
c Select the IPRoutes page and note that the default routes have reappeared.
d Repeat step 3(g) above.
e You may wish to ping the Primary Call Server to verify that you can communicate with the
Primary, eg ping 194.168.0.1
The Secondary Call Server will now be a part of the system controlled by the Primary Call Server. The
Primary Call Server will replicate the relevant configuration information to the Secondary Call Server. This
means that the configuration of the system can be administered from either Call Server.
Connecting a Phone or Trunk Module to the Secondary Call Server
A Phone or Trunk module can be connected to the Secondary Call Server as described on page 39 and
page 43.
The Call Server field within the Phone or Trunk Module's configuration form will display the name of the
Call Server that the module it is connected to, ie the name of the Secondary Call Server.
When connecting a Phone Module to a Secondary Call Server the additional Users created are all listed
under the Users list and have taken the next available extension numbers. Their Initial Phone field
displays which port on which Phone Module they are using and their Current Home field, which
determines which Call Server is providing their voicemail service, displays the name of the Secondary Call
Server.
Connecting a PCS to the Secondary Call Server
A PCS 580/570/560, PCS410/400, PCS 100, PCS 60 IP phone or PCS 50 IP phone can be connected to the
Secondary Call Server as described in the Connecting a PCS section from page 48.
The Initial Phone field within the User's configuration form will display which Call Server the PCS is
connected to, ie the name of the Secondary Call Server. Please refer to page 81 for further details.
Select Phones and then the relevant Call Server to display which PCSs are connected to this Call Server.
Connecting an existing Primary Call Server to another Primary Call Server
Where a Call Server has been previously working as a standalone system and is now to be connected to
another system the same method described above is used however the following should be noted:
