Installation and Reference Manual
e The PCS 60 will now appear under Phones, identified by the hardware address of the PC
6 The "Security Access Denial" message will be displayed while an IPUser licence is assigned.
7 A User account will be automatically created configured with the next available extension number.
This User will be assigned to the PCS 60, the "Security Access Denial" message will disappear and
the PCS 60 will be ready for use. The name of the assigned User will be displayed in the Status Bar
at the bottom left hand corner of the PCS 60.
The User's Initial Phone field displays the PCS 60 that the User is assigned to, identified by the
hardware address of the PC.
Connect to the Call Server remotely
If the PCS 60 is to be run remotely over, a different subnet, a VPN, for example, the application must be
configured with the IP address of the gatekeeper, in other words the Call Server, before the registration
process can take place. This can be done in two ways:
1 Using PCS 60 Preferences
a From the File menu select Preferences
b In the IP Address field enter the IP address of the
Call Server, eg 192.168.0.1
c Select OK (Window only
d Close down the PCS 60 and run the software
again.
2 Using the PCS 60's short cut properties
a Open the Properties of the PCS 60's short cut
60
System Operation
Installation and Reference Manual v3.2/0410/6
