Installation and Reference Manual
4400 Voice Compression Module
As an alternative to the 64kbps, G.711 voice supported as standard on maximiser, 8kbps, G.729a based
encoding, provides an excellent balance between voice quality and bandwidth efficiency. The 4400 Voice
Compression Module provides 16 channels, of 8 kbps, G.729a based compression and can be deployed
to provide a higher density of calls between 4100 Call Servers/4140 Remote Call Servers over low speed
WAN links.

maximiser Handsets

PCS 580G
This IP phone provides:
Message waiting/do not disturb "S" LED
•
Dual Mode – SIP (configured via the Call Server) & H.323
•
Fully integrated with the LDAP system database for viewing and annotating customer records and
•
notes
Integral web browser
•
Can be wall mounted
•
Can be partnered with PCS 60 or PCS 50
•
6
1 x RJ45 port, dual speed, 10/100 Mbps FDX Ethernet
•
interface with integral LEDs for Link and Data.
1 x 48Vdc Power jack.
•
Supports G.729a
•
Additional 16 channels enabled via a licence, giving
•
a maximum of 32 compression channels per module
Standard telephony functionality
•
Graphical colour touch screen LCD interface
•
Context Sensitive Screen
•
Ability to display real time video and graphical information
•
during call
Power - 802.3af Power over Ethernet
•
2 Port 10/100/1000 Mbps FDX LAN switch – supporting
•
automatic MDI-MDIX crossover, Diffserv Quality of Service,
802.1q VLAN and 802.3af Power over Ethernet
2 x USB port – USB 2.0 interface for WiFi and external
•
keyboard
Headset connection
•
Wide-angle tilting keypad/display panel
•
Platform Overview
Installation and Reference Manual v3.2/0410/6
