Line distance protection REL670 2.2
Product version: 2.2

26. Ordering for pre-configured IED

Guidelines
Carefully read and follow the set of rules to ensure problem-free order management.
Please refer to the available functions table for included application functions.
PCM600 can be used to make changes and/or additions to the delivered factory configuration of the pre-configured.
To obtain the complete ordering code, please combine code from the tables, as given in the example below.
Example code: REL670 *2.2-A41X00- X00B05-B1X0-AC-CA-B-A6X0-CL1AB1RGN1N1XXXXXXX-KKKXXHKKLAGXSY. Using the code of each position #1-11 specified
as REL670*1-2 2-3-4 4-5 6-7 7-8-9 9 9-10 10 10 10 10 10 10 10-11 11 11 11 11 11 11 11 11 11 11
# 1 - 2
REL670* 2.2 -
10
SOFTWARE
Version number
Version no.
Configuration alternatives
Single breaker, 1/3 phase tripping, isolated or high impedance earthed systems
Single breaker, 1/3 phase tripping
Multi breaker, 1/3 phase tripping
Single breaker, 1/3 phase tripping, with PMU
ACT configuration
ABB standard configuration
Software options
No option
High impedance differential protection - 3 blocks
Phase segregated scheme communication
Pole slip protection
Stub protection
Sensitive directional residual overcurrent and power protection
Directional power protection
Overexcitation protection - 2 winding
Frequency protection - line
General current and voltage protection
Fuse failure supervision based on voltage difference
Autorecloser - 1 circuit breaker
Autorecloser - 2 circuit breakers
Control functionality for up to 10 objects
Control functionality for up to 15 objects
IEC 62439-3 parallel redundancy protocol
IEC 62439-3 High-availability seamless redundancy
IEC 61850-9-2 Process Bus communication, 8 merging units
Synchrophasor report, 8 phasors
ABB
- 3
X00 -
- 4
-
- 11
-
Selection for position #1
Ordering no
1MRK004003-EG
1MRK004003-FG
1MRK004003-GG
1MRK004003-HG
Selection for
position #2
Ordering no
1MRK004001-AB
1MRK004001-BE
1MRK004001-VU
1MRK004001-VK
1MRK004001-CT
1MRK004001-VM
1MRK004001-DC
1MRK004001-ED
1MRK004001-FA
1MRK004001-HC
1MRK004001-GD
1MRK004001-GE
1MRK004001-GW
1MRK004001-GY
1MRK004001-PP
1MRK004001-PR
1MRK004001-PT
1MRK004001-PV
Selection for
position #3
1MRK 506 372-BEN -
- 5 6 - 7 - 8 - 9
- - - -
Position
#1 Notes and rules
2.2
#2 Notes and rules
A41
A42
B42
D42
X00
#3 Notes and rules
X00 All fields in the ordering form do
not need to be filled in
A02 Only for A42/B42/D42
B05
B24 Only for A42/B42/D42
B27 Only for B42. One block included
as basic.
C16 Only for A42/B42/D42
C39 Only for A42/B42/D42
D03
E04 One block included as basic
F01 Only for A42/B42/D42
G03
H04 Only for A42/D42. One block
included as basic.
H05 Only for B42. Two blocks included
as basic.
H37 Only for A41/A42/D42
H38 Only for B42
P23 Options P23 and P24 require two
SFPs placed in pairs.
P24
P30
P32 Only for A41/A42/B42
-
-
