Power Supply Board Terminal Identification; Access Power Controller Terminal Identification - Altronix Maximal11FD Installation Manual

Terminal
Function/Description
Legend
L, N Connect 120VAC 60Hz to these terminals: L to hot, N to neutral. Do not use terminal marked [G]
+ DC – Factory connected to ACM8CB board.
Trigger EOL Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally open,
Supervised normally closed from an FACP output circuit (power-limited input) (Fig. 3, pg. 8).
NO, GND
FACP interface latching or non-latching (power-limited) (Fig. 3, pg. 8).
RESET
+ AUX – Auxiliary Power-Limited output rated @ 1 amp (unswitched) (power-limited output) (Fig. 3, pg. 8).
AC FAIL Indicates loss of AC power, e.g. connect to audible device or alarm panel. Relay normally energized
NC, C, NO when AC power is present. Contact rating 1 amp @ 30VDC (power-limited) (Fig. 3, pg. 8).
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized when DC power
BAT FAIL
is present. Contact rating 1 amp @ 30VDC. A removed battery is reported within 5 minutes.
NC, C, NO
Battery reconnection is reported within 1 minute (power-limited) (Fig. 3, pg. 8).
+ BAT – Stand-by battery connections. Maximum charge current 1.54 amp (non power-limited) (Fig. 3, pg. 8).
Terminal Legend Function/Description
12VDC or 24VDC from power supply/charger (factory connected).
-- Power +
These terminals are paralleled to the - Control + terminals.
These terminals are paralleled to the - Power + terminals.
-- Control + These terminals can be connected to an external Listed power-limited access control power supply to provide isolated
operating power for the devices (Not evaluated by UL) (jumpers J1 and J2 must be removed).
TRIGGER
From normally open and/or open collector sink trigger inputs
INPUT 1-INPUT 8
(request to exit buttons, exit pir's, etc.)
IN, GND
12VDC to 24VDC trigger controlled outputs. Maximum load per output is 2 amp.
Maximal11FD: P/S 1 - 9.8-13.2VDC @ 3.3 amp P/S 2 - 9.8-13.2VDC @ 3.3 amp or
P/S 1 - 19.9-26.4VDC @ 3.6 amp P/S 2 - 19.9-26.4VDC @ 3.6 amp or
P/S 1 - 9.8-13.2VDC @ 3.3 amp and P/S 2 - 19.9-26.4VDC @ 3.6 amp.
Maximal33FD: P/S 1 - 9.7-13.2VDC @ 5.3 amp P/S 2 - 9.7-13.2VDC @ 5.3 amp or
P/S 1 - 19.8-26.4VDC @ 5.6 amp P/S 2 - 19.8-26.4VDC @ 5.6 amp or
OUTPUT 1-
P/S 1 - 9.7-13.2VDC @ 5.3 amp and P/S 2 - 19.8-26.4VDC @ 5.6 amp.
OUTPUT 8
NC, C, NO, COM
Maximal55FD: P/S 1 - 9.7-13.2VDC @ 9.3 amp and P/S 2 - 9.7-13.2VDC @ 9.3 amp.
Maximal75FD: P/S 1 - 9.7-13.2VDC @ 9.3 amp and P/S 2 - 19.8-26.4VDC @ 9.6 amp.
Maximal77FD: P/S 1 - 19.8-26.4VDC @ 9.6 amp and P/S 2 - 19.8-26.4VDC @ 9.6 amp.
Fail-Safe [NC positive (+) & COM Negative (-)], Fail-Secure [NO positive (+) & COM Negative (-)], Auxiliary output [C
positive (+) & COM Negative (-)] (When using AC power supplies polarity needs not to be observed). Contacts shown
in a non-triggered state.
FACP INTERFACE Fire Alarm Interface trigger input from FACP. Trigger inputs can be normally open,
T, + INPUT -- normally closed from an FACP signaling circuit output (Figs. 5-9, pg. 10).
FACP INTERFACE
Form "C" relay contact rated @ 1 amp 28VDC for alarm reporting (not evaluated by UL).
NC, C, NO
Maximal11FD/Maximal33FD/Maximal55FD/Maximal77FD/Maximal75FD Access Power Controllers (PTC)

Power Supply Board Terminal Identification:

Access Power Controller Terminal Identification:

- 6 -
