Rotary gripper module
pneumatic / electric
GMQ 20 / RE-50
GMQ 20 / RE-50
Declaration of Incorporation
Module Information
Montage Instructions
Maintenance Instructions
„Translation" of the Original Operating Instructions
© Copyright by Afag Automation AG
18-100V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GMQ 20/RE-50 and is the answer not in the manual?

Questions and answers

Related Manuals for Afag GMQ 20/RE-50

Summary of Contents for Afag GMQ 20/RE-50

  • Page 1 Rotary gripper module pneumatic / electric GMQ 20 / RE-50 GMQ 20 / RE-50 18-100V Declaration of Incorporation Module Information Montage Instructions Maintenance Instructions „Translation“ of the Original Operating Instructions © Copyright by Afag Automation AG...
  • Page 2 These operating instructions apply to: Type Order No. Type Order No. GMQ 20/P / RE-50 50355544 GMQ 20/P / RE-75 18-100V 50355547 GMQ 20/P-01 / RE-50 50410326 GMQ 20/P-01 / RE-75 18-100V 50410327 GMQ 20/K / RE-50 50355546 GMQ 20/K / RE-75 18-100V 50355549 Assembly and initial start-up must be carried out by qualified personnel only and ac-...

  • Page 3: Table Of Contents

    Table of Contents 1.0 Declaration of Incorporation ................5 2.0 Module Information ..................…7 2.1 Safety ........................7 2.2 Transport, Handling, Storage ................6 2.3 Module Desgription ....................7 2.4 Nomenclature construction gripper rotary Module…………………………………8 2.5 GMQ 20 / RE-50 18-100V…………………………………………………………….9 2.6 Mounting of the gripping pliers ................
  • Page 4 4.0 Maintenance Instructions ................4.1 Servicing ......................29 4.2 Further maintenance ................... 30 4.3 Possible failures on rotary module RE-50 ............31 4.4 Exchanging the gripper actuator (pnematically/electric) ........32 4.5 Exchanging the RE-50 rotary module ..............34 4.6 End position sensor replacement ................ 34 4.7 Spare parts ......................
  • Page 5 EC directive: 2006/42 /EC Norme: EN ISO 12100:2010 Agent: For the compilation of the technically relevant documents: Niklaus Röthlisberger, Producte Manager Afag Automation AG, CH-4950 Huttwil Place/Date: Huttwil, 07.03.2016 Siegfried Egli Niklaus Röthlisberger Managing Director Producte Manager HT...

  • Page 6: Module Information

    Safety Modifications to the rotary-gripper module that are not described in this operating manual or have not been approved in writing by the company Afag Automation AG are not permitted. In case of improper changes or assembly, installation, operation, maintenance or repairs, Afag Automation AG rejects all liability.

  • Page 7: Nomenclature Construction Gripper Rotary Module

    2.4 Nomenclature construction gripper rotary modules GMQ 20 RE-50 18-100V 20-RE-50 OI. vers.1.4 gb. 07.03.2016...

  • Page 8: Gmq 20 / Re-50 18-100V

    2.5 GMQ 20 RE-50 18-100V pneumatically / electric Gripper Servo drive with gears Encoder housing Proximity switch Encoder connection Motor connection Adapter unit Gripper actuator Air connection Connecting flange 20-RE-50 OI. vers.1.4 gb. 07.03.2016...

  • Page 9: Mounting Of The Gripping Pliers

    2.6 Mounting of the gripping pliers Pliers can be retrofitted to rotary-gripper modules which were ordered without pliers. The EG-20 gripper actuator can be fitted with the standard gripper pliers of the GMQ 20 pneumatic grippers. There are 3 different types available. 1 Centering bushings 2 Gripper 18-100V...

  • Page 10: The Gripper Fingers Are Not Included

    Insert cylinder pin in the flange holes so that the gripper pliers is locked. Loosen screw using the Allen screwdriver. Cylinder pin Loosen clamping screw at the gripper pliers. The pliers head can be removed Drawbar New gripper pliers can now be mounted on the rotary gripper.

  • Page 11: Assembly Connection

    2.8 Assembly connection WARNING Due to the rotating movement of the gripper pliers, hair or other materials may be caught and drawn into the system while the module is being operated. Caution: Commissioning may only be executed by qualified personnel. WARNING Always switch off the controller and protect it against being switched on again unintentionally when you work on the rotary-...

  • Page 12: Centering Module

    Thread Tightening moments 0,3 … 0,35 Nm 0,5 … 0,73 Nm M2.5 1,1 … 1,4 Nm 2,6 … 3,3 Nm 5,2 … 6,5 Nm 9,0 ... 11,3 Nm 21,6 ..27,3 Nm Table 1: Tightening moments for screw 2.10 Centering module 20-RE-50 OI.

  • Page 13: Installation In A System

    2.11 Installation in a system DANGER The gripper rotary engine may not be used in hazardous envi- ronments. WARNING If add-ons at the rotary-gripper module could cause danger in connection with moving parts a safe operation must be en- sured. Ensure that the operator cannot reach into the operating range of the rotary-gripper module during normal operation.

  • Page 14: Turning The Rotary Module If The Cable Outlets Don't Fit

    NOTE This operating manual should be read carefully before carrying out any activity on or with the rotary-gripper module. 2.12 Turning the rotary module if the cable outlets don’t fit In the delivery state the cable connections on the rotary module are facing forward. You can turn the black mounting part so that the cable outlets are pointing to the left or right side.
  • Page 15 Procedure: Loosen 4 screws on the RE-50 using the 2.5 mm allen screw- driver Remove the RE-50 turn to the desired side and remount. Bolt down the RE-50 in the new position. 20-RE-50 OI. vers.1.4 gb. 07.03.2016...

  • Page 16: Montage Instructions

    EC di- rective: 2006/42/EC Standard: EN ISO 12100:2010 (German Version) Agent: For the compilation of the technically relevant documents: Niklaus Röthlisberger, Products Manager Afag Automation AG, CH-4950 Huttwil 20-RE-50 OI. vers.1.4 gb. 07.03.2016...

  • Page 17: Intended Use

    3.1 Intended use The rotary-gripper modules are used for the smooth rotary movement of loads in non-explosion hazardous ambient and operating conditions that are specified for this module (see Technical Data). The rotary-gripper modules are exclusively intended for rotating useful loads (see Technical Data) which do neither impair the safety of persons nor present a danger to property and the environment.

  • Page 18: Warranty

    Modifications on the module that are not described in this operating manual or have not been approved in writing by Afag are not permitted. In the case of improper changes or assembly, installation, operation, maintenance or repairs, Afag AG re- jects all liability.

  • Page 19: Dimension Drawing: Gmq 20-Re-50

    3.4 Dimensional drawing: GMQ 20 RE-50 Figure 1: Dimension drawing GMQ 20-RE-50 20-RE-50 OI. vers.1.4 gb. 07.03.2016...

  • Page 20: Technical Data Gmq 20

    3.5 Technical data GMQ 20 RE-50 18-100V Tabelle 2: Technische Daten EG-20 RE-50 20-RE-50 OI. vers.1.4 gb. 07.03.2016...

  • Page 21: Technical Data Re-50

    3.7 Rotation time RE-50 3.8 Installation of external modules The rotary flange is designed for the attachment of Afag modules. If third party mod- ules are used the rotary flange can also be removed. The engineer can also make an own rotary flange which can be attached to the third party modules.
  • Page 22 3.9 Gripper Dimension 20-RE-50 OI. vers.1.4 gb. 07.03.2016...
  • Page 23 20-RE-50 OI. vers.1.4 gb. 07.03.2016...

  • Page 24: Electrical Interfaces

    3.9 Electrical Interface Motor cable (M12 or M15) brown withe 3 PE blue black Encoder cable (G10 or G12) brown blue withe green pink yellow black grey + 5 V violet grey/pink red/blue with/green brown/green with/yewllow n.v. yellow/brown n.v. with/grey n.v.

  • Page 25: Sensor Plug

    3.10 Sensor plug M5x0.5mm 3.11 Commissioning, operation, training WARNING Due to the rotating movement of the gripper pliers, hair or other materials may be caught and drawn into the system while the module is being operated. Caution: Commissioning may only be executed by qualified personnel.

  • Page 26: Preparation For Commissioning

    The rotary-gripper module is designed for operation with Afag servo controllers. They can also be operated with other controller types. Operation of the Afag servo controllers is described in the separate operating instruc- tions. First connect the servo controller to a PC on which the operating software was in- stalled and carry out the test run.

  • Page 27: Commissioning

    3.13 Commissioning Carry out the first start-up slowly and step by step. Note the permissible technical data (see catalogue) regarding: load capacity motion frequency moment load CAUTION Limbs may be crushed by moving components. Make sure that there are no persons or tools within the operating range of the module.

  • Page 28: Normal Operation

    3.15 Normal operation WARNING Due to the rotating movement of the gripper pliers, hair or other materials may be caught and drawn into the system while the module is being operated. If add-ons at the rotary-gripper module could cause danger in connection with moving parts a safe operation must be en- sured.

  • Page 29: Maintenance Instructions

    4.0 Maintenance Instructions 4.1 Servicing WARNING Due to the rotating movement of the gripper pliers, hair or other materials may be caught and drawn into the system while the rotary-gripper module is being operated. Observe the operating instructions of the system into which the rotary-gripper module was incorporated.

  • Page 30: Further Maintenance

    4.2 Further maintenance Under the ambient conditions mentioned below the rotary-gripper module does not require any further maintenance: clean workshop atmosphere no splash water no friction dust or dust from processing climate and temperature according to the technical data. Troubleshooting and repair WARNING Due to the rotating movement of the gripper pliers, hair or other materials may be caught and drawn into the system while the...

  • Page 31: Possible Failures On Rotary Module Re-50

    Motor connection inter- Check motor cable rupted Drive defective Have the drive replaced by Afag AG Rotary shaft (gripper pli- Important contouring error Reduce values for accel- ers) stops after a short eration and speed turn Check whether module...

  • Page 32: Exchanging The Gripper Actuator (Pnematically/Electric)

    In addition you will need a special tool which must be ordered separately. Afag AG offers professional repairs. The module must be returned to Afag for this purpose. Procedure for remplacement of the GMQ 20 Undo and remove 4 screws on the RE- 50 module.
  • Page 33 Loosen pivot bearing using the mounting wrench so that the bear- ing can be removed together with the drawbar. Loosen clamping screw at the mid- dle part Pivot bearing with drawbar Mounting wrench Gripper actuator Adapter unit 20-RE-50 OI. vers.1.4 gb. 07.03.2016...

  • Page 34: Exchanging The Re-50 Rotary Module

    4.5 Exchanging the RE-50 rotary module If a rotary module turns out to be defective after the warranty period, carry out the following steps to replace the module yourselves: Order the rotary module from Afag: RE-50 Order no. 50294005 RE-50 18-100V Order no.

  • Page 35: End Position Sensor Replacement

    Sensor 4.7 Spare parts NOTE Repair of the rotary-gripper module should only be carried out by Afag. There are no spare parts available. 20-RE-50 OI. vers.1.4 gb. 07.03.2016...

  • Page 36: Accessories

    4.8 Accessories Type Order No. Centering sleeves 7x3mm 11016850 see technical catalog Centering sleeves 9x4mm 11004942 Flange set RE-50 50294008 Flange set RE-50 50294009 Motor cable-M12-5m-0-open (SE-Power) 50290459 Motor cable-M12-10m-0-open (SE-Power) 50310506 Motor cable-M12-5m-90-open (SE-Power) 50290460 Motor cable-M12-10m-90-open (SE-Power) 50310507 Motor cable-M15-3m-0-0 (SE-24/48) 50332418 Motor cable-M15-3m-90-0 SE-24/48)

  • Page 37: Extension And Repair

    4.9 Extension and repair When the module is damaged it can be returned to Afag Automation AG for repair. WARNING Before disassembly the power supply must be switched off and disconnected. Disassembly of the system may only be started after the power supply was definitely disconnected.
  • Page 38 20-RE-50 OI. vers.1.4 gb. 07.03.2016...
  • Page 39 20-RE-50 OI. vers.1.4 gb. 07.03.2016...
  • Page 40 Afag Automation AG Fiechtenstrasse 32 4950 Huttwil Switzerland Tel.: +41 62 959 86 86 Fax.: +41 62 959 87 87 e-mail: sales@afag.com Internet: www.afag.com...
