Kanomax 2211 Operation Manual

Iaq monitor
Hide thumbs Also See for 2211:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
IAQ MONITOR
MODEL 2211
Operation Manual
Please use this instrument properly by reading
this user's manual and following the warning instructions.
Keep this manual in a place where it can be accessed quickly.
ＫＡＮＯＭＡＸ ＪＡＰＡＮ ＩＮＣ.
2-1 Shimizu Suita Osaka
Zip:565-0805
Phone: +81(6)6877-0183
０２００１
Fax : +81(6)6879-2080
０4．11
1.800.561.8187
information@itm.com
www.
.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2211 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kanomax 2211

Summary of Contents for Kanomax 2211

  • Page 1 IAQ MONITOR MODEL 2211 Operation Manual Please use this instrument properly by reading this user’s manual and following the warning instructions. Keep this manual in a place where it can be accessed quickly. ＫＡＮＯＭＡＸ ＪＡＰＡＮ ＩＮＣ. 2-1 Shimizu Suita Osaka...
  • Page 2 Thank you for purchasing Kanomax product. Please use this instrument properly by reading this operation manual and following the warning instructions. 1.800.561.8187 information@itm.com www. .com...
  • Page 3 List of Components ■ Standard Items Functions MODEL Qty. Main Body 2211-00 － Probe 2211-01 CO, CO , temperature, humidity sensor Carrying case 2211-02 Hard case Probe stand 2211-03 Probe fixture Gas Calibration cap 2211-04 Gas calibration Tubing － Connecting to gas tank Operation Manual －...

  • Page 4: Table Of Contents

    Table of Contents 1. IAQ Monitor Anatomy..............1 1.1 Main Body..........................1 1.2 Operation Panel........................2 1.3 Probe............................3 2. Getting Started................4 2.1 Installing Batteries ......................... 4 2.2 Connecting Probe........................5 2.3 Disconnecting Probe......................5 2.4 Powering IAQ Monitor ON/OFF ..................6 2.5 How to make measurement .....................
  • Page 5 7. Other Setting ................33 7.1 Date.............................33 7.2 Units and Baud Rate ......................34 7.3 To Delete Data........................35 7．３．１ To Delete a Page of Data ..................... 35 7．３．２ To Delete All Data ........................36 7.4 Contrast Adjustment......................37 8. Calibrating CO/CO Sensor............38 8.1 Preparation..........................38 8.2 Calibration Procedure –...

  • Page 6: Iaq Monitor Anatomy

    1. IAQ Monitor Anatomy 1.1 Main Body Approx.. 88 Unit： mm Probe Terminal Display Analog output Terminal (Optional) RS232C Terminal Input Ternimal Power Switch I ：ＯＮ Ｏ：ＯＦＦ Operation Panel IAQ MONITOR Battery Box Approx. 66 1.800.561.8187 information@itm.com www. .com...

  • Page 7: Operation Panel

    1.2 Operation Panel MENU KEY Press once to access the main menu.. ※ If you press this key while measuring or setting, this key will work as CANCEL and bring you back to the main menu. …………………………Normal Mode ……………Calculation Mode …………………………………Ventilation Ratio Mode ……………To download data to your PC or printer ………………To delete data or Printer...

  • Page 8: Probe

    1.3 Probe Unit： mm φ25 ＣＯ sensor Temperature sensor Humidity sensor ＣＯ sensor ２ φ15 φ32 Probe number L=2000 1.800.561.8187 information@itm.com www. .com...

  • Page 9: Getting Started

    2. Getting Started 2.1 Installing Batteries Place IAQ Monitor facedown. ①Press down on the battery cover. ②Slide the cover until it stops. ③Lift the cover away from the body. ④Insert the battery observing the polarity. This instrument requires 6 AA size batteries. Use only AA size Manganese (R6), alkaline (LR6) or Ni-Cd batteries for replacement.

  • Page 10: Connecting Probe

    2.2 Connecting Probe ※ Make sure that the power is OFF when connecting or Disconnecting Probe/Probe cable. ① Main Body connector and probe connector only fit one way. ① ②Push-in the connector until you hear click. ※ DO NOT FORCE to connect Probe, it may cause a serious damage to the instrument.

  • Page 11: Powering Iaq Monitor On/Off

    2.4 Powering IAQ Monitor ON/OFF You can turn ON and OFF the IAQ Monitor by flicking the switch on the side. When you turn on the power after connecting Probe , Manufacturer’s logo, model name and its software version appear on the display for a few seconds.

  • Page 12: How To Make Measurement

    2.5 How to make measurement 2.5.1 Measuring CO and CO and Attentions The diffusion state of the air(State of flow) affects response time of CO and CO sensor. In order to obtain an exact measurement result, please measure in the place which has the flow of air as much as possible.

  • Page 13: Measuring Temperature And Attentions

    <Compensation> when atmospheric pressure of the place to measure is different from normal atmospheric pressure (such as high altitude), Please follow below steps for Atmospheric pressure setting (Initial value: 1013hPa). Since the change of weather does not significantly affect the atmospheric pressure as long as the place to measure is same (Exclude the case of typhoon), you need to set Atmospheric Pressure only 1 time.

  • Page 14: Measuring Humidity And Attensions

    2.5.3 Measuring Humidity and Attensions High humidity or rapid temperature change in atmosphere may cause humidity reading value to be exceedingly high because of the condensation occurred on this sensor. Incase of the condensation, leave a probe under atmosphere of less than 40%RH for 24 hours to dry. Comparison: Assman Aspirated Psychrometer The quality and accuracy of IAQ Monitor humidity measurement function is ensured by strict calibration with traceability in Japanese National Standards of JEMIC (Japan Electric Meters...

  • Page 15: Normal Measurement

    3. NORMAL Measurement This is the mode that you will be in, when you first turn on the instrument. In this mode you cannot save any data. The display will be updated every 1 second. To move to NORMAL Mode from other measuring mode, Press to select “1.

  • Page 16: Display Hold

    ⑤ <Absolute Humidity> ⑥ <Temperature Ratio> 3.2 Display Hold Display Procedure While measuring, Press (Also available on Humidity measuring.) “HOLD” indicator appears on the display to indicate that the reading shown is held. Press again to release. Maximum Hold・・・How to Hold the Maximum Value Display Procedure While measuring, press and hold...

  • Page 17: Measuring Maximum, Minimum & Mean

    4. Measuring Maximum, Minimum & Mean Calculation Mode will automatically calculate the maximum, minimum and mean of measured data. TRIAL(1) TRIAL(2) TRIAL(N) ● Average (AVG) AVG＝ΣTRIAL(N)/N ● Maximum (MAX) MAX＝TRIAL(i) Sampling Time ● Minimum MIN＝TRIAL(j) Measuring Time・・・ Sampling Time × Ｎ（Number of Trial） Display Procedure Press...
  • Page 18 Display Procedure ＜To Set CALCULATION MODE＞ and select “1. MODE” Press and select AVERAGE or INSTANT Press ＜To Set SAMPLING TIME＞ and select “2. SAMPLING TIME” Press and select SAMPLING TIME (1 to 999sec）. Press ＜To Set No. TRIAL (N)＞ and select “3.
  • Page 19 ＜READY＞ Press to start. Display Procedure ＜While Measuring＞ Press to stop. If you have selected “ YES ” for “ 4. DATA STORAGE ?”, the measured data will be stored. Press can also stop the measurement but this would not store any data.

  • Page 20: Oa Mode

    5. %OA Mode ％OA MODE is to provide calculation of ventilation ratio with temperature or CO Calculation is based on below formula: Open Air (O_A) %OA＝(R_A - S_A)／(R_A – O_A)×100 * %OA： Ventilation Ratio Respiration (R_A) R_A： Temperature and CO in respiratory air S_A：...
  • Page 21 Display Procedure Press press and Select [3.OA%] . <To Set Sampling Time > to Select [1.MODE] Ｐress to Select [TEMP.] or [CO2] Ｐress %OA MODE (Ventilation Ratio Measurement) Display Icons 1. Calculation MODE TMP. ： To calculate by taking in temperature value.
  • Page 22 Display Procedure <DATA STORAGE> Press to select [4.DATA STORAGE], Press and select [YES] or [NO], Press <SET TO START> and select [5.SET TO START], Press ※ If you press before saving the settings it will return you back to Main Menu. <Ready>...
  • Page 23 Display Steps <Result> After all the trials are finishied, the calculated result will appear in display. Press to display average values in order of : R_A, S_A, and O_A. Press to return to main MENU. If you have selected [YES] for [DATA STORAGE], the result will be stored.

  • Page 24: Data Output

    6. DATA OUTPUT 6.1 What can be Stored ? Measuring Display Stored Parameters , CO, temperature, humidity CALCULATION Mode （including the items of humidity） Temp. %OA; R_A, S_A, and O_A temperature %OA Mode %OA; R_A, S_A, and O_A CO concentration 6.2 To Recall Stored Data Display Procedure...
  • Page 25 Display Procedure <Recalled Data> Recalled data will be displayed. for scroll. CALCULATION If you measured in calculation mode, you can select TEMP. Data number Temperature or Humidity to be displayed by pressing ％OA (温度の場合) < Set Calibration Range> You can select the range of calculation. （If you are not going to change the data range, Press calculate the entire data.）...

  • Page 26: Print Out

    6.3 Print Out RS232C Port You can connect IAQ Monitor to a printer using an RC232C cable for data printout. 6.3.1 Preparation <Need to have> - Printer (optional)……….. DPU-H245 (Seiko Instruments) - recommended - Printer Cable （optional） <Check the Baud Rate > You need to coordinate the baud rate and data transmission conditions on both Main Body and the printer.

  • Page 27: Calculation Mode Print Out

    Examples of Print Out <NORMAL Mode> 2004/05/12 15:40:45 …………CO …………CO Temperature 24.4 ﾟ C …………Temperature Humidity 52.7 %RH …………Humidity 6.3.3 CALCULATION Mode Print Out Display Procedure Press after the measurement and calculation to print out the result. 1.800.561.8187 information@itm.com www. .com...

  • Page 28: Oa Mode Print Out

    6.3.4 %OA Mode Print Out Display Procedure Press after %OA measurement and calculation to print out the result. Examples of Print Out <CALCULATION Mode> <%OA Mode> PAGE SET PAGE SET PAGE :002 PAGE :004 Stored Location MODE :%OA(TMP.) Measurement Mode MODE :CALCULATION(I) DATE :2004/06/19 DATE :2004/06/19...

  • Page 29: Stored Data Print Out

    6.3.5 Stored Data Print Out Display Procedure Press to select [4.DATA OUTPUT], Press to select [2.PRINTER], Press to select page that you want to print out, press ……………………………Page number ………Measurement Mode(Calculation (A): AVERAGE, (I): INSTANT) ………………Measured Date (Year / Month / Day) ………………Measured Time (Hour : Minute : Second) ……………………………Number of Trial/Number of Measuring Point The data you have selected will be displayed.
  • Page 30 <Set Print Out Range> You can select the range of calculation. （If you are not going to change the data range, press to calculate the entire data.） Press Cursor will appear on “START” to select starting point. Press Cursor will move to “END” to select l.
  • Page 31 Ｅｘａｍｐｌｅ ｏｆ Ｐｒｉｎｔ Ｏｕｔ <CALCULATION Mode> <%OA Mode> PAGE SET PAGE SET PAGE :011 PAGE :002 MODE : CALCULATION(I) MODE :%OA(TMP.) Condition DATE :2004/06/21 DATE :2004/06/19 (Always printed out) TIME :16:23:08 TIME :13:35:23 ATM. :1013hPa ATM. :1013hPa DATA :005 DATA :010 SAMPLING TIME :001 SAMPLING TIME:001 START:001 END:005...

  • Page 32: Digital Output

    6.4 Digital Output RS232C Port 6.4.1 Preparation You can download the data stored in IAQ Monitor to your PC, by connecting IAQ Monitor and your PC with the RC232C cable. <Need to Have> - Computer - RS-232C cable (provided) - Data Processing Software （Software for Windows DC-ROM is provided） <Check the Baud Rate >...

  • Page 33: To Access From Your Pc

    6.5 To Access From Your PC Command Function To connect IAQ Monitor to your PC, please Ｄ＊＊＊＊ Number of Downloading Data refer to p.27. Ｎ Cancel Ｓ Output of Measuring Condition (of ―――Icons and its Meaning――― On-Time Data) ： Space Ｕ...

  • Page 34: Transmission Of Stored Memory

    Display Procedure <To Download Measuring Units > [U ] Press After “AU”, the data will be displayed. ppm;ppm;ﾟ C;%RH;ﾟ C;ﾟ C;g/m3;g/kg;% Output CO Unit; CO Unit; temperature Unit; humidity Unit ; DT Unit; WB Unit; AH Unit; HR Unit; OA% Unit 6.5.2 Transmission of Stored Memory Display Procedure...

  • Page 35: Analog Output (Optional)

    Display Procedure <To download measurement condition> CTH;000;001;003;AVG;1013 Press “M＊＊＊＊ ” (※Must type in 4 digits) Type in the desired page number after “AM”. ① ② ③ ④ ⑤ Contents ③ Number of Data ① Measuring Mode ④ Calculation setting 000: CALCULATION Mode CALCULATION -- AVG: average, INS: Instant 001: %OA Mode %OA -- TMP: temperature CO2;...
  • Page 36 Of the output range, the low end will be set at 0V and the high end will be set at 1V . Data output interval is always 1 second. Way To Take In Measured Data Explanation （analog output） Take the data at every 1 second, output the value every 1 second.
  • Page 37 <To save the setting> to select [3.SAVE INFO]. Press ※If you Press before you save, you will return to Main Menu and setting will not be saved. 1.800.561.8187 information@itm.com www. .com...

  • Page 38: Other Setting

    7. Other Setting 7.1 Date DISPLAY PROCEDURE Press to select “7. UTILITY”. Press to select “1. TIME ADJUST”. Press to select "1.STYLE" or "2.DATE". Press 1.STYLE: Select JP,US or EU Japanese style(JP) YYYY/MM/DD US style(US) MM/DD/YYYY EU style(EU) DD/MM/YYYY 2.DATE: Date 3.TIME: hour/minute/sec to select the desired item.

  • Page 39: Units And Baud Rate

    7.2 Units and Baud Rate ＜Units Conversion Table＞ Temperature Ｔ（ F）＝1.8×Ｔ（℃）＋32 Absolute Humidity 1(g/m ）＝6.24×10 (ｌｂ/ft ） Humidity 1(g/kg）＝9.9999×10 (ｌｂ/lb） DISPLAY PROCEDURE Press to select “6. UTILITY”. Press to select “2. UNIT SELECT”. Press to select the desired item （1 thru 5）. Press ……Temperature: ℃...

  • Page 40: To Delete Data

    7.3 To Delete Data 7．３．１ To Delete a Page of Data DISPLAY PROCEDURE Press to select “6. DATA CLEAR”. Press to select “1. CLEAR”. Press ……Starting Page Number ……Ending Page Number ……Partial Delete (YES or NO) ……All Delete （YES or NO） ……Remaining Memory / Total Memory to select the starting page.

  • Page 41: 7．３．２ To Delete All Data

    Selected page will be deleted and the remaining data will shift up. (See diagram below) Page １ Page １ Page １ Page ２ Page ２ Page ２ Page ３ Page ４ Page ３ Page ４ Page Number will change automatically 7．３．２...

  • Page 42: Contrast Adjustment

    7.4 Contrast Adjustment In case you find the LCD display of Main Body too dark or too light, there is an adjusting volume at the back, bottom of Main Body, inside the battery cover. You can adjust by using a precision driver (-) （0.9～1.5mm）. Turn it clockwise to darken and vice versa.

  • Page 43: Calibrating Co/Co Sensor

    8. Calibrating CO/CO Sensor 8.1 Preparation Please turn on the main unit to fully warm up (about 10 minutes) before calibration. In general, calibrate in order of ZERO gas prior to Span gas (The calibration of only either ZERO gas or Span gas is possible).

  • Page 44: Calibration Procedure - Zero Calibration

    8.2 Calibration Procedure – ZERO Calibration Display Procedure Connect ZERO gas tank and IAQ Monitor. Press to select [7.CALIBRATION] Press to select sensor (1.CO2 or 2.CO). Press . (CO2 is selected in the example.) to select [ZERO]. Press to select [1.ZERO], press ……Currently calibrating sensor （CO or CO2）...
  • Page 45 ‘‘‘‘ to select [YES]. Press to start calibration. Fully open the regulator valve to pour the gas flow, Press to start calibration. Standby screen: The initial value of countdown is displayed. Unit: Second. ………………………………Calibration is performing. ………………………………The remaining time to a calibration end. When the calibration result is OK Calibration is completed.

  • Page 46: Calibration Procedure - Span Calibration

    Calibration result is NG ……The value after calibration …………………Calibration is completed …………………Calibration Result Operation If [END] is displayed, the valve of regulator will be closed and Gas will be stopped. … … ※ If [2.SAVE INFO] will not be able to be selected, the result is - CO2 concentration maintains above 200ppm for more than 30 seconds.
  • Page 47 to select [1.SPAN]. Range of CO mass: 20-550ppm Press to display a cursor. Range of CO mass: 800-5500ppm to enter a concentration value displayed on a gas tank, Press ………………Concentration value displayed on gas tank ……The valve before calibration to select [YES]. Press ･････････････････････････････Standby display ・...
  • Page 48 Calibration Result is OK Calibration is completed. ……The value after calibration …………………Calibration is completed ………………… Calibration result Operation If [END] is displayed, the valve of regulator will be closed and Gas will be stopped. … … - CO concentration maintains below 60% of standard value for more than 30 seconds.

  • Page 49: Specification

    9. Specification Product IAQ Monitor Model 2211 Object Clean air flow Method Electrochemical Range 0.0-50.0 ppm（0.0~500 ppm*） Resolution 0.0-99.9ppm:0.1ppm,100-500ppm:1ppm Accuracy ±3% of displayed value or ±3ppm; whichever that is larger （@20℃） Compensation: Temp ±0.125 %FS/℃ （within ‐20-40℃: standard is 20℃）...

  • Page 50: Calculation Result: Dt, Wb, Ah, And Hr

    10. Calculation Result: DT, WB, AH, and HR 10.1 What is DT DT -- Dew Point Temperature Air with higher temperature contains more water vapor, and the air reaches a saturation point as temperature lowered （Relative humidity: 100％）. Then continuously lowered temperature causes water vapor to start condensing -- this temperature is called Dew Point Temperature.

  • Page 51: What Is Wb

    10.2 What is WB Wet Bulb Temperature -- WB Wet-bulb temperature is measured with a wet-bulb thermometer, which is a regular thermometer with a wet muslin wick cover. To calculate wet-bulb temperature without using a wet-bulb thermometer, existing dry-bulb temperature and relative temperature are used on the aspirated psychrometer humidity table that is JIS standard Z8806 compliant.

  • Page 52: What Is Hr

    10.4 What is HR Humidity Mixture Ratio -- -HR Humidity Ratio (mixture ratio) is the proportion of masses between water vapor and dry air. Temperature and relative humidity are used on below formula. Society of Heating, Air-conditioning and Sanitary Engineers of Japan ｒ＝ε×e/(p-e) ×1000 ε: Molar mass ratio = 0.62198 e: Water vapor （Pa）...

  • Page 53: Troubleshooting

    “ ‐ ‐ ‐ ‐ ” is displayed for →Check the connection. measured value. Probe may be damaged. →Contact your local Kanomax Office or service center. IAQ Monitor is not displaying Probe sensor may be too close to expiratory air. the right speed.

  • Page 54: Printer Check

    11.4 Printer Check Refer To Problem Possible Cause(s) / Solution(s) (Page No.) Unable to printout. Printer is not connected properly. →Check the connection. Re-connect if necessary. The Baud Rate is not set properly. →Check both, CLIMOMASTER and printer, settings. Printer may not be compatible (DPU-H245 and DPU-201GS are recommended).

  • Page 55: Calibration Check

    11.7 Calibration Check Refer To Problem Possible Cause(s) / Solution(s) (Page No.) [-ERR] appears during the CO Output level of CO sensor may be abnormal or the sensor is SPAN calibration. damaged. Contact a distributor near you. (Although SPAN calibration is not available, you can use existing calibration value when output level is low.) [-ERR] appears during the CO Output level of CO...

  • Page 56: １2．Warranty And After Service

    １2．Warranty and After Service Kanomax Limited Warranty The limited warranty set below is given by KANOMAX JAPAN, Inc. (hereafter referred to as “KJI”) with respect to the KANOMAX brand IAQ Monitor, its attachment parts including Probe and other accessories (hereafter referred to as “PRODUCT”) that you have purchased.

  • Page 57: After Service

    After Service Whenever the PRODUCT is malfunctioning, please check with “Troubleshooting” to find possible cause first. Repair parts are retained for a minimum period of five (5) years after production cessation of the PRODUCT. This storage period of repair parts is considered as the period during which KJI can provide repair service. For more information, please contact your local distributor, or call us at KJI’s service desk from 9:00 a.m.
