- Page 1 User Guide Kanomax S200 Handheld Multi-Gas Monitor netzerotools.com...
- Page 2 netzerotools.com Quick Start Guide Unpack monitor and check supplied components are correct Insert Battery (see section 3.0) Insert Sensor When new, plug in the power adaptor and turn on your monitor (with sensor head installed) for 24hrs. Note: The battery requires 15hrs from full discharge.
-
Page 3: Table Of Contents
netzerotools.com Contents 1.0 Monitor Components 2.0 About Your Monitor 3.0 Assembly and Installation 3.1 Battery pack 3.2 Sensor warm up 3.3 Monitor and Sensor Versions 4.0 Operating Instructions 4.1 Turning the Monitor on and off 4.2 Operating under battery power 4.3 Sensor Head Failure 4.4 Using the Menus &... -
Page 4: Monitor Components
netzerotools.com 1.0 Monitor Components Series 200 Monitor The following components are supplied with the Series 200 Monitor: • Series 200 monitor base • Gas sensor head • 12 VDC 800 mA AC/DC adaptor • User guide • Battery pack – 9.6 V Please check that all these components have been supplied and contact your dealer if any of the components are missing. -
Page 5: About Your Monitor
netzerotools.com 2.0 About Your Monitor The Aeroqual Series 200 Monitor has been specifically designed to incorporate Aeroqual’s in-depth knowledge of accurate ambient gas measurement. Different sensor heads are used for specific gases or depending upon whether high or low concentrations are to be meas- ured. -
Page 6: Assembly And Installation
netzerotools.com 3.0 Assembly and Installation Assembly The following needs to be completed before the Monitor is ready for use: - • Insert the sensor head into the top of the monitor. The sen- sor head is keyed to ensure the head is inserted correctly. •... - Page 7 netzerotools.com Removing the Battery Pack • Remove the battery cover from the monitor. • Insert your thumb under the top left hand side of the battery pack and carefully lever the battery pack out from the retain- ing clips. • Unclip the connector from the monitor. •...
- Page 8 netzerotools.com Charging and Discharging the Batteries New Ni-MH batteries must be fully charged prior to use. A new Ni- MH battery's full performance is achieved only after a number of complete charge and discharge cycles. A fully charged battery will run for approximately 4-5 hours.
-
Page 9: Sensor Warm Up
netzerotools.com Installing the AC/DC adaptor • Connect the AC/DC adaptor to the mains supply. Ensure that the adaptor is correctly rated for the power supply. • Plug the adaptor into the monitor. The monitor can now be used as a mains unit. If the monitor is to be used as a port- able unit the batteries will need to be charged. -
Page 10: Operating Instructions
netzerotools.com 4.0 Operating Instructions The following instructions detail the operation and set up of the monitor. Power Enter button 4.1 Turning the monitor on and off To turn the monitor on, press & hold the power button until the screen activates. The monitor will turn on and the display will show “AEROQUAL MONITOR S200 / S205 Vx.x”,. -
Page 11: Operating Under Battery Power
netzerotools.com Turning Standby Mode on and off To activate Standby Mode with the monitor on, press the power button once. This will stop operation of the monitor; however the sensor will be kept warm. This mode is used to conserve power between operations but keep the sensor ready to measure the gas concentration with only a short warm up phase as described in “Warm up”... -
Page 12: Using The Menus & Key Functions
netzerotools.com 4.4 Using the Menus and Key Functions To enter the setup menu press The following menus will appear: - Normal Menu Special Perc Menu EXIT EXIT ZERO CAL ZERO CAL CONC UNIT CONC UNIT MIN MAX AV MIN MAX AV ALARM MUTE ALARM ALARM LEVEL... -
Page 13: Changing Unit Of Measurement
netzerotools.com 4.6 Changing Unit Of Measurement (Concentration Unit) To enter the ‘CONC UNIT’ menu press . The unit display will appear. OZONE UNIT: ppm (or) mg/m 3’ Press to scroll between ‘ppm’ or ‘mg/m Press to confirm the unit selection Press to scroll down to the next Menu choice 4.7 The Max/Min/Average Measurement Cycle... -
Page 14: Alarm Mute (Perc Only)
netzerotools.com 4.8 ALARM MUTE (for PERC only) Note: With “Alarm Mute ON” (enabled) the alarm condition will be muted only until the gas concentration drops below the alarm level – remember this is a temporary mute function. To enter the “ALARM MUTE” menu press and the following screen will appear: - ALARM MUTE... -
Page 15: Alarm Level (Perc Only)
netzerotools.com If you select “Alarm Permanent OFF” and exit the menu, the symbol will be displayed on the gas concentration screen to indicate that the alarm has been permanently muted. Press to scroll down to the next menu choice. 4.10 ALARM LEVEL (for PERC only) To enter the “ALARM LEVEL”... -
Page 16: Troubleshooting
netzerotools.com 5.0 Troubleshooting Series 200/205 Fault Description Possible cause Remedy No power Lead connection broken Reconnect power lead Power supply failure Replace 12V DC power supply Battery flat Recharge battery S200 damaged Replace unit Sensor head damaged Replace sensor head Sensor failure Insufficient warm up Run the sensor on full power for... - Page 17 netzerotools.com Fault Description Possible cause Remedy Reading higher than Sensor correct Check calibration of gas expected in the pres- generator. ence of sensor gas Interferent gas pre- Move sensor to clean air sent and check reading upon exposure to known gas concentration Sensor calibration lost Replace /refurbish sensor...
-
Page 18: Specifications
netzerotools.com 6.0 Specifications Series 200 Monitor Base Measurement units PPM or mg/m Removable / replaceable sensor head On-board alarm* Alarm status displayed * Low battery indication Alarm mute function* Sensor condition status Stand-by mode External signal for alarms & control None External signal functions None... -
Page 19: Drawings
netzerotools.com 7.0 Drawings Depressions in the battery cover demarcating the screw-hole posi- tions for fixing the unit to the wall netzerotools.com... -
Page 20: Care And Maintenance
netzerotools.com 8.0 Care and Maintenance Your Aeroqual Monitor is a product of superior design and quality and should be treated with care. When using your Aeroqual Monitor: • Keep it and all its parts and accessories out of the reach of small children. -
Page 21: For Your Safety
netzerotools.com 9.0 For Your Safety Read these simple guidelines. Ignoring these guidelines may be hazard- ous. USE SENSIBLY Use only as per this user guide. USE AEROQUAL APPROVED SERVICE Only approved service personnel must work on this product. ACCESSORIES Use only approved accessories. Do not connect incompatible products. -
Page 22: Statements Of Compliance
netzerotools.com 10.0 Statements of Compliance The Aeroqual Series 200 Monitor and Remote Adaptor Kit comply with EN 50082-1:1997 The Aeroqual Series 200 Monitor and Remote Adaptor Kit comply with EN 50081-1:1992 The Aeroqual Series 200 Monitor and Remote Adaptor Kit comply with Part 15 of the FCC Rules. -
Page 23: Warranty
netzerotools.com 11.0 Warranty Thank you for purchasing this Aeroqual product. To get maximum use of the features of your new product we recommend that you follow a few simple steps: Read the guidelines for safe and efficient use. Read all the terms and conditions of your Aeroqual Warranty. Save your original receipt. - Page 24 netzerotools.com Conditions • The warranty is valid only if the original receipt issued to the original purchaser by the dealer, specifying the date of purchase, is presented with the product to be repaired or replaced. Aeroqual reserves the right to refuse warranty service if this information has been removed or changed after the original purchase of the product from the dealer.
-
Page 25: Copyright
netzerotools.com 12.0 Copyright Copyright Aeroqual Limited. All rights reserved. Reproduction, transfer, distribution or storage of part or all of the contents of this document in any form without the prior written permission of Aeroqual Limited is pro- hibited. “Aeroqual” and “Aeroqual Limited – Making the Invisible Visible” are registered trademarks of Aeroqual Limited. -
Page 26: Guidelines On How To Measure Ozone
netzerotools.com 13.0 Guidelines on How to Measure Ozone The following information is presented to help users operate their Aeroqual monitor with an ozone sensor installed in the most effective and efficient manner. General • Ozone is heavier than air and tends to sink. Thus detection of leaks from ozone generating equipment should be per- formed at the most appropriate position. -
Page 27: Zero Calibration Additional Information
netzerotools.com 14.0 Zero calibration additional Information A zero calibration menu routine is included in the Series 200, however it is important to understand when this should be used. All Aeroqual sen- sors are supplied pre-calibrated and zero calibration is performed in the factory in an atmosphere containing <... -
Page 28: Sensors And Accessories
netzerotools.com 15.0 Sensors and accessories Gases Ranges Ammonia (NH 0 - 100 ppm 0 - 1000 ppm Carbon monoxide (CO) 0 - 100 ppm 0 - 1000 ppm Carbon dioxide (CO 0 - 2000 ppm 0 - 5000 ppm 0 - 5% Hydrogen (H 0 - 5000 ppm Hydrogen sulphide (H...
