Hi Res
Increases the displayed Gage resolution as follows:
NOTE:
Gage accuracy is not affected.
Fast
Increases measurement speed for most probes. Useful for quick
inspection or when measuring large areas with thick coatings
where proper probe positioning is not critical. Swift up/down probe
movement is required. Reduced accuracy may be noted.
Scan
By default, the PosiTector 6000 takes approximately 1 reading
per second. Scan mode allows the user to take multiple readings
in rapid succession (3 readings per second) without lifting the
probe. Choose from 3 Scan modes:
•Normal - continuously measures when placed on the surface
•Statistics - displays real-time scan statistics when placed on the
surface. Average, max., min., and standard deviation are displayed.
•Limited # Avg. - continuously measures until user-specified number of
readings is reached, then displays the average for the scan.
When Memory is on (pg.6), Scan measurement data is
recorded. However, in Statistics and Limited # Avg. Scan
modes, only the statistics and/or avergage is saved, not
individual readings. Note that performing a scan may reduce the
life of the probe and is recommended for smooth surfaces only.
For additional information concerning Scan mode, visit
http://www.defelsko.com/scan
Resolution
0.01 mil
0.1 mil
0.1 um
1.0 um
Range
0.00 - 99.00 mils
100.0 - 999.9 mils
0.0 - 999.9 um
over 1000 um
(Advanced models only)
15
