3. Familiarization

3.1 Front View

CO Sensor
Location
Protective
Rubber Boot
USB Port
Sensor Locations:
Display :
Protective Rubber Boot
Keypad
USB Port
Power Adapter Socket
CO2 Sensor
Location
Places where the CO, CO2, and Humidity sensors
are located and protected.
Large 4 Parameter Backlit LCD Display.
Provides protection to meter housing and sensors.
Selects all available functions
Location for connection of USB cable for PC com
munication.
Location to connect power adapter.
Humidity &
Temperature
Sensor Location
Display
Keypad
Power Adapter
