22.6.1.1.7 I2CDRR Register (Offset = 6h) [reset = 0h]
I2CDRR is shown in
Return to Summary
I2C Data receive
15 14
7 6
Bit Field
15-8 RESERVED
7-0 DATA
1938
Inter-Integrated Circuit Module (I2C)
Figure 22-22 and described in
Table.
Figure 22-22. I2CDRR Register
13 12
RESERVED
5 4
Table 22-16. I2CDRR Register Field Descriptions
Type Reset
R 0h
R 0h
Copyright © 2015–2017, Texas Instruments Incorporated
Table 22-16.
11 10
R-0h
3 2
DATA
R-0h
Description
Reserved
Receive data
