3.1

Microprocessors

The IMB500 Series supports Intel
enable your system to operate under Windows
Linux environments. The system performance depends on the microprocessor. Make sure all
correct settings are arranged for your installed microprocessor to prevent the CPU from
damages.
3.2

BIOS

The IMB500 Series uses AMI Plug and Play BIOS.
3.3

System Memory

The IMB500 supports four 288-pin DDR4 DIMM sockets for maximum memory capacity up to
64GB DDR4 SDRAMs. The memory module comes in sizes of 2GB, 4GB, 8GB and 16GB.
Hardware Description
Hardware Description
®
Core™ i7/ i5/ i3, Pentium
®
7 32/64-bit, Windows
IMB500 LGA1151 ATX Motherboard
Chapter 3
® ®
and Celeron processors, which
®
8.1, Windows
®
10 and
23
