General Information
Part number
X13790903
X13790904
X13641194
Dimensions
The dimensions of the WCI enclosure are as follows:
3.386 in. (86.00 mm)
4.677 in. (118.80 mm)
2.480 in. (63.00 mm)
0.581 in. (14.76 mm)
0.650 in. (16.50 mm)
6
Description
Bulk version of X13790901, no wiring harness, no installation instructions. For factory ordering
in bulk.
Bulk version of X13790902, no wiring harness, no installation instructions. For factory ordering
in bulk.
Outdoor enclosure to protect WCI from harsh environments or wet indoor environments.
2.896 in. (73.55 mm)
0.118 in. (3.00 mm)
1.344 in. (34.14 mm)
2.620 in. (66.55 mm)
1.419 in. (36.03 mm)
R0.71 in. (R1.80 mm) TYP
0.236 in. (6.00 mm)
BAS-SVX40A-EN
