Mounting and Wiring the WCI

Follow these instructions:
Hazardous Service Procedures!
Disconnect all electric power, including remote disconnects before servicing. Follow proper
lockout/tagout procedures to ensure the power can not be inadvertently energized. Failure to
disconnect power before servicing could result in death or serious injury.

Controller Applications

1. Remove power from the controller that is to have the WCI wired to it.
2. Remove the WCI cover by firmly pressing the thumb tab at the bottom of the cover and pulling
Figure 3. Removing the cover
3. Secure the backplate to the mounting surface using appropriate hardware. (M3.5 x 20 mm self-
4. Attach the 4-connector screw terminal block on the wiring harness to the receptacle on the WCI
Figure 4. Connecting wiring harness
12
the cover away from the back plate
Note: If present, remove the security screw before removing the cover.
drilling screws are provided.)
(Figure 4).
WARNING
(Figure 3).
Red = +24 Vdc/ac
Black =
Blue = LINK +
Gray = LINK -
