5. Route the wires from the WCI through either:
Figure 5. Routing the wires through the WCI backplate (a) or bottom exit port (b)
6. Connect the wiring harness according to the illustration that is appropriate for your application:
7. Restore power to the controller.
8. The network is ready to be formed. Refer to
BAS-SVX40A-EN
a. The opening in the back plate
b. The bottom exit port (Figure
(a)
Note: Wiring between a WCI and a controller cannot exceed 656 ft (200 m). If the wiring
harness does not provide enough length, use 18 AWG (24 pF/ft max.) communication
wire (Trane purple wire).
• To wire the WCI to a Tracer SC, see
• To wire the WCI to a UC400 or a UC600, see
• To wire the WCI to a BCI-I, see
• To wire the WCI to a BCI-R, see
Important: The WCI must be wired to the controller prior to power up in order to establish
network communication.
Mounting and Wiring the WCI
(Figure 5, a).
5, b).
(b)
Figure 6, p. 14.
Figure 7, p.
Figure 9, p. 15.
Figure 10, p. 15.
"Establishing the Network, " p.
14.
17.
